Redondance de réseaux
10.1 Spanning Tree Protocol (STP)
Opéra‐
3
4
5
Exemple
Dans l'exemple suivant, on définit ethernet0/1 explicitement comme port d'extrémité.
localhost# config
Entering configuration mode terminal
localhost(config)# interface ethernet0/1 spanning-tree edge-port enable
localhost(config-interface-ethernet0/1-spanning-tree)# commit
Commit complete.
localhost(config-interface-ethernet0/1-spanning-tree)# end
localhost# show running-config interface ethernet0/1 spanning-tree edge-
port
interface ethernet0/1
spanning-tree
edge-port enable
exit
exit
10.1.3.5
Sélection du type de lien d'un port de pont
RSTP utilise un protocole point à point qui permet une transition rapide pour les connexions
point à point. Ce protocole est automatiquement désactivé lorsque plusieurs ponts STP
communiquent via un réseau local partagé (pas de connexion point à point).
384
Instruction
tion
Validez la modification.
Quittez le mode de configuration.
Contrôlez la configuration.
Commande
commit
end
show running-config interface
{ Port de pont } spanning-tree
edge-port
Command Line Interface (CLI) SINEC OS V2.4
Manuel de configuration, 10/2023, C79000-G8977-C498-07
