ELECTRICAL CIRCUIT
LIGHTING
Fig.51
1. Earth
2. Beacon switch
3. Wash wipe switch
4. Hazard Warning Switch
5. Flasher Relay
6. Direction Indicator Switch
7. Head light switch
8. Side Lamp LH Front
9. Side Lamp RH Front
10. Relay 3
11. Side Lamp LH Rear
12. Side Lamp RH Rear
13. Number Plate Lamp RH
14. Head Lamp LH
15. Head Lamp RH
16. Indicator Lamp LH Front
17. Indicator Lamp LH Rear
18. Indicator Lamp RH Front
19. Indicator Lamp RH Rear
20. Wipe motor
21. Blower
22. Wash motor
23. Beacon
24. Horn
GB
F5 Fuse
F6 Fuse
F7 Fuse
F8 Fuse
F9 Fuse
F10 Fuse
F11 Fuse
F12 Fuse
F13 Fuse
CABLE COLOUR CODE
R Red
G Green
O Orange
S Grey
B Black
W White
K Pink
P Violet
Y Yellow
U Blue
N Brown
LG Light Green
Note:
Circuit connectors are indicated on the diagram
by a letter 'A', 'C', 'D', followed by a number
GB-NL-F-75
