ELECTRICAL CIRCUIT
ENGINE AND SAFETY
Fig.50
1. Battery
2. Starter motor and solenoid
3. Alternator
4. Relay 1
5. Relay 2
6. Timer
7. Relay 4 heater
8. Relay 3 starter
9. Engine heater (glow plugs)
10. Seat switch
11. Fuel pump
12. Engine oil pressure switch
13. Fuel sender
14. Temperature sender
15. To horn
16. Four wheel drive valve
17. Engine over temperature switch
18. Forward / reverse switch
19. Mow switch
20. Stop solenoid
21. Isolation switch
22. Alarm relay
23. Horn button
24. Beacon fuse
25. Key switch
26. Connections to light circuit
27. Earth
28. Instrument panel connectors
GB
F1 Fuse
F2 Fuse
F12 Fuse
FL1 Fuse
FL3 Fuse
FL2 Fuse
D1 Diode
D2 Diode
D3 Diode
D4 Diode
CABLE COLOUR CODE
R Red
G Green
O Orange
S Grey
B Black
W White
K Pink
P Violet
Y Yellow
U Blue
N Brown
LG Light Green
Note: Circuit connectors are indicated on the
diagram a letter 'A', 'B', 'E', followed by a number
GB-NL-F-69
