Fig.46
Fig.47
END OF SEASON
SERVICING
MACHINE
The machine should be thoroughly cleaned down to
remove all accumulations of grass clippings and
debris.

HYDRAULIC TANK

Drain oil from hydraulic tank by removing drain plug.
Clean plug and replace. Replace hydraulic oil filter
canister (see below) and refill tank (A Fig.46) with
Shell Tellus 46 hydraulic oil to correct level. Capacity
approximately 52 litres (11.44 Imp.gals) (13.73 US
gals)
NOTE: Absolute cleanliness must be observed
when filling the hydraulic tank.
HYDRAULIC OIL FILTER
The filter canister (A Fig.47) should be removed and
discarded. Replace with a new one before refilling
hydraulic tank. Run the machine and recheck level of
oil in the tank, top up if necessary with Shell Tellus
46.
DIVERTER VALVES
Thoroughly clean the diverter valves and operating
mechanism. Oil the spools and all exposed parts to
prevent corrosion.
