Textron RANSOMES Commander 3510 Manuel page 171

SOLENOID CONTROL
CIRCUIT AND SENSOR
Abb. 52
1. Fussschalter Schneidwerk
2. Magnetschalter Schneidwerk
3. Fussschalter Differentialsperre
4. Magnetschalter Allradantrieb
5. Magnetschalter Differentialsperre
6. Schalter Allradantrieb
7. Erde
D
F3 Fuse
F4 Fuse
CABLE COLOUR CODE
R Red
G Green
O Orange
S Grey
B Black
W White
K Pink
P Violet
Y Yellow
U Blue
N Brown
LG Light Green
Note:
Circuit connectors are indicated on the diagram
by a letter ' A', 'B', followed by a number
D-I-75
