DAZE Power Manager Manuel D'installation page 5

General Specifications
Compatible Products
1
Electrical Specifications
Maximum power counter
2
Maximum current for phase
3
* The 100 kW Power Manager Module is only compatible with Dazebox Home, Dazebox Share, Duo, and Urban
Installation
Number of current sensors
4
Maximum phase cable section
5
Charger connection cable
6
(*it is not guaranteed that cables of a higher category than Cat5e are
suitable for the provided shielded RJ45 connectors)
Network cable shielding
7
Length of current sensor connection cable - CT box
8
Connection to CT box
9
Maximum network cable length from CT box to charger
10
Mounting
11
Single-phase
PM02M / PM03M
Dazebox C: DB07**M* / DB07**T* / DB07**M*** / DB07**T***
Dazebox Home: DT01**32** / DS01**32** / DK01**32**P / DS01**32*P
Dazebox Share: DT02**32** / DS02**32** / DK01**32**P / DS01**32*P
Duo: OT01**64**** / OS01**64***
Urban: UT01IT64T***** / US01IT64T*****
12,5 kW
55 A
1
Up to 50 mm
2
Shielded CATe* network cable
F o S/FTP - SF/FTP - SF/UTP - F/UTP
DIN rail or screw mounting (PM) / Freestanding (Compact PM)
three-phase
PM02T /PM02T100
PM03T30 /PM03T100
37,5 kW / 100 kW *
55 A / 145 A
3
Up to 50 mm / Up to 120 mm
2
900 mm
Jack 3,5 mm
170 m
