4
4.1
4.1.1
8200vec291
 Loose both screws in order to remove the housing cover. The assembly kit can be found under the housing cover.
‚ Mounting of the fixing brackets
ƒ Dimensions
0
Drive controllers can be mounted side-by-side with a certain space to each other.
Controller
E82EV153K4B2x1 ELN3-0088H035
E82EV223K4B2x1 ELN3-0075H045
E82EV303K4B2x1 ELN3-0055H055
L

Mechanical installation

E82EV153K4B ... E82EV303K4 mounting

Fixing bracket (standard) and mains choke

Mains choke a [mm] b1 [mm]
250 250 350 350
Mechanical installation
Mounting E82EV153K4B ... E82EV303K4B
c [mm] c1 [mm] d [mm] d1 [mm] d2 [mm]
205 205 22 22 402 402 24 24
EDK82EV903 DE/EN/FR 1.0
e [mm] g [mm] k [mm]
370 370 250 250 6.5 6.5 24 24
m [mm]
11 11
