Commissioning
Code table
Code
No. Name
C0111 Configuration analog
v
output X3/62
(AOUT1-IN) ( )
C0114 Level inversion
v
digital inputs E1 ...
E6 E6
54
Possible settings
Lenze Selection
Analog signal output to terminal
0
0 Output frequency with slip (MCTRL1-NOUT+SLIP)
1 Controller load (MCTRL1-MOUT)
2 Apparent motor current (MCTRL1-IMOT)
3 DC-bus voltage (MCTRL1-DCVOLT)
4 Motor power
5 Motor voltage (MCTRL1-VOLT)
6 1/output frequency (1/C0050) (MCTRL1-1/NOUT)
7 Output frequency with limits (NSET1-C0010...C0011)
8
Operation with process controller (C0238 = 0, 1):
Act. process controller value (PCTRL1-ACT)
Operation without process controller (C0238 = 2):
Output frequency without slip (MCTRL1-NOUT)
9 Ready for operation (DCTRL1-RDY)
10 TRIP fault message (DCTRL1-TRIP)
11 Motor is running (DCTRL1-RUN)
12 Motor is running / CW rotation (DCTRL1-RUN-CW)
13 Motor is running / CCW rotation (DCTRL1-RUN-CCW)
14 Output frequency = 0 (DCTRL1-NOUT=0)
15 Frequency setpoint reached (MCTRL1-RFG1=NOUT)
16 Frequency threshold Q
17 I limit reached (MCTRL1-IMAX)
max
C0014 = -5-: Torque setpoint reached
18 Overtemperature (J
19 TRIP or Q or pulse inhibit (IMP) active
min
(DCTRL1-TRIP-QMIN-IMP)
20 PTC warning (DCTRL1-PTC-WARN)
21 Apparent motor current < current threshold
(DCTRL1-IMOT<ILIM)
22 Apparent motor current < current threshold and Q
threshold reached (DCTRL1-(IMOT<ILIM)-QMIN)
23 Apparent motor current < current threshold and RFG
1: Input = output (DCTRL1-(IMOT<ILIM)-RFG-I=0)
24 Warning motor phase failure (DCTRL1-LP1-WARN)
25 Minimum output frequency reached (PCTRL1-NMIN)
255 Freely configured under C0419/1
0 T1/T2 E6
6 5
2 2
0 0 0
1 0 0
2 0 0
3 0 0
...
127 1 1
EDK82EV903 DE/EN/FR 1.0
reached (PCTRL1-QMIN)
min
- 5 °C) (DCTRL1-OH-WARN)
max
min
E5 E4 E3 E2 E1
4 3 2 1 0
2 2 2 2 2
0 0 0 0 0
0 0 0 0 1
0 0 0 1 0
0 0 0 1 1
...
1 1 1 1 1
IMPORTANT
Change of C0111 is copied to C0419/1. Free
configuration in C0419/1 sets C0111 =
-255-!
6 V/12 mA ≡ C0011
3 V/6 mA ≡ Rated motor torque with vector
control (C0014 = 4), otherwise rated active
inverter current (active current/C0091)
3 V/6 mA ≡ Rated inverter current
6 V/12 mA ≡ DC 1000 V (400 V mains)
6 V/12 mA ≡ DC 380 V (240 V mains)
3 V/6 mA ≡ Rated motor power
4.8 V/9.6 mA ≡ Rated motor voltage
2 V/4 mA ≡ 0.5 × C0011
0 V/0 mA/4 mA ≡ f = f (C0010)
min
6 V/12 mA ≡ f = f (C0011)
max
6 V/12 mA ≡ C0011
Selection -9- ... -25- corresponds to the digital p
functions of the relay output K1 (C0008) or the f i f h l K1 (C0008)
digital output A1 (C0117): digital output A1 (C0117):
LOW = 0 V/0 mA/4 mA LOW = 0 V/0 mA/4 mA
HIGH = 10 V/20 mA HIGH = 10 V/20 mA
Belt monitoring
Apparent motor current = C0054 pp
Current threshold = C0156
Only display
Do not change C0111 since settings under
C0419/1 can be lost
•
The binary value of the selected number
determines the input levels:
– 0: Ex is not inverted (HIGH active) – 0: Ex is not inverted (HIGH active)
– 1: Ex is inverted (LOW active)
• •
C0114 and C0411 are identical C0114 and C0411 are identical
•
E5, E6 only application I/O
• •
T1/T2 can only be connected to T1/T2 can only be connected to
potential-free switches:
– 0: T1/T2 is not inverted (active, if switch is 0 T1/T2 i t i t d ( ti
closed)
– 1: T1/T2 is inverted (active, if switch is 1 T1/T2 i i t d ( ti if
open) p )
Th f The function "Parameter set changeover" ti "P t t h
cannot be inverted!
L
g
h
if it h i
it h i
"
