Delivery package
2.2 E82EV453K4B ... E82EV903K4B
Item
8200 vector frequency inverters
Mounting Instructions
a
Fixing bracket
b
Socket connector, 4-pole
c Socket connector, 3-pole
d Cable tie 3.6 150 mm
e Hexagon head screw, M8 16 mm (DIN933)
f Washer, ∅8.4 mm (DIN125)
g Spring-lock washer, ∅ 8 mm (DIN127)
10
a
c
Number for E82EV
453K4B/553K4B 753K4B/903K4B
1
1
4
1
1
4
4
4
4
EDK82EV903 DE/EN/FR 1.0
b
e
g
f
Use
1
1
4 For standard mounting of the drive controller
1 Relay output connection 2
1 Relay output connection 1
4 Strain relief/shield connection for motor cable
8 Mounting of the fixing brackets at the drive controller
8 For hexagon head screw, M8 16 mm
8 For hexagon head screw, M8 16 mm
d
8200vec267
