Code
No. Name
C0419 Free configuration of
v
analog outputs l
(continued)
C0420* Gain analog output
X3/62 (AOUT1-GAIN)
Standard I/O
C0420* Gain analog outputs
Application I/O
(A)
1 X3/62 (AOUT1-GAIN)
2
L
Possible settings
Lenze Selection
g
Analog signal output to terminal
Analog signal source
27 Output frequency without slip (MCTRL1-NOUT)
28 Act. process controller value (PCTRL1-ACT)
29 Process controller setpoint (PCTRL1-SET1)
30 Process controller output without precontrol
(PCTRL1-OUT)
31 Ramp function generator input (NSET1-RFG1-IN)
32 Ramp function generator output (NSET1-NOUT)
33 (A) PID controller output (PCTRL1-PID-OUT)
34 (A) Process controller output (PCTRL1-NOUT)
35 Input signal at X3/8 or X3/1U, X3/1I,
evaluated with gain (C0414/1 or C0027) and offset
(C0413/1 or C0026) (AIN1-OUT)
36 Input signal at frequency input X3/E1,
evaluated with gain (C0426) and offset (C0427)
(DFIN1-OUT)
37 Motor potentiometer output⋅(MPOT1-OUT)
38 Input signal at X3/2U, X3/2I,
evaluated with gain (C0414/2) and offset (C0413/2)
(AIN2-OUT)
40 AIF input word 1 (AIF-IN.W1)
41 AIF input word 2 (AIF-IN.W2)
50 ... 53 CAN-IN1.W1 ... 4 oder FIF-IN.W1 ... FIF-IN.W4
Word 1 (50) ... word 4 (53)
60 ... 63 CAN-IN2.W1 ... 4
Word 1 (60) ... word 4 (63)
255 Not assigned (FIXED-FREE)
128 0
128 0
{1}
{1}
EDK82EV903 DE/EN/FR 1.0
Commissioning
Code table
IMPORTANT
6 V/12 mA/5.85 kHz ≡ C0011
6 V/12 mA/5.85 kHz ≡ C0011
6 V/12 mA/5.85 kHz ≡ Maximum value analog
input signal (5 V, 10 V, 20 mA, 10 kHz)
Condition: Gain of analog input or frequency g p
input set to: i t t t
C0414/x, C0426 = 100 %
Setpoint to drive from communication module to
AIF AIF
10 V/20 mA/10 kHz ≡ 1000
Setpoints to drive from function module to FIF
10 V/20 mA/10 kHz ≡ 1000
255 128 ≡ Gain 1
C0420 and C0108 are the same
128 ≡ Gain 1
255 C0420/1 and C0108 are the same
