Commissioning
Code table
Code
No. Name
C0415 Free configuration of
v digital outputs
1 Relay output K1
(RELAY) ( )
2 Digital output X3/A1
( (DIGOUT1) )
3 (A) Digital output X3/A2
(DIGOUT2)
68
Possible settings
Lenze Selection
Output of digital signals to terminals
25 0 Not assigned (FIXED-FREE)
255
1 PAR-B0 active (DCTRL1-PAR-B0)
2 Pulse inhibit active (DCTRL1-IMP)
16
3 I limit reached (MCTRL1-IMAX)
max
(C0014 = -5-: Torque setpoint reached)
4 Frequency setpoint reached (DCTRL1-RFG1=NOUT)
255 5 Ramp functin generator 1: Input = output
(NSET1-RFG1-I=O)
6 Q threshold reached (PCTRL1-QMIN)
min
7 Output frequency = 0 (DCTRL1-NOUT=0)
8 Controller inhibit active (DCTRL1-CINH)
9...12 Reserved
13 Collective message:
(DCTRL1-OH-PTC-LP1-FAN1-WARN)
Overtemperature (ϑ
or
Motor overtemperature (DCTRL1-LP1-PTC-WARN)
or
Motor failure (DCTRL1-LP1-WARN)
or
Fan failure (not active)
14 DC-bus overvoltage (DCTRL1-OV)
15 CCW rotation (DCTRL1-CCW)
16 Ready for operation (DCTRL1-RDY)
17 PAR-B1 active (DCTRL1-PAR-B1)
18 TRIP or Q or pulse inhibit (IMP) active
min
(DCTRL1-TRIP-QMIN-IMP)
19 PTC warning (DCTRL1-PTC-WARN)
20 Apparent motor current < current threshold
(DCTRL1-IMOT<ILIM)
21 Apparent motor current < current threshold and Q
threshold reached (DCTRL1-(IMOT<ILIM)-QMIN
22 Apparent motor current < current threshold and RFG
1: Input = output (DCTRL1-(IMOT<ILIM)-RFG-I=0)
23 Warning motor phase failure (DCTRL1-LP1-WARN)
24 Minimum output frequency reached (PCTRL1-NMIN)
25 TRIP fault message (DCTRL1-TRIP)
26 Motor is running (DCTRL1-RUN)
27 Motor is running/CW rotation (DCTRL1-RUN-CW)
28 Motor is running/CCW rotation (DCTRL1-RUN-CCW)
29 Process controller input = process controller output
(PCTRL1-SET=ACT)
30 Reserved
31 Apparent motor current
function generator 1: Input = output
(DCTRL1-(IMOT>ILIM)-RFG-I=0)
32 ... 37 X3/E1 ... X3/E6, X3/E1 (32) ... X3/E6 (37)
38 X2.2/T1, X2.2/T2
EDK82EV903 DE/EN/FR 1.0
IMPORTANT
•
•
RFG1 = Ramp function generator main setpoint
active PAR-B1 PAR-B0
PAR1 PAR1
PAR2 PAR2
PAR3 PAR3
PAR4
-5 °C) (DCTRL1-OH-WARN)
max
set C0597 = 2
set C0119 = 2 or C0119 = 5
absolutely set C0608 = 0
set C0119 = 2 or C0119 = 5
Belt monitoring
Apparent motor current = C0054 pp
Current threshold = C0156
min
set C0597 = 2
current threshold and ramp Overload monitoring
>
Apparent motor current = C0054
Current threshold = C0156
Digital input terminals
PTC input
A selection under C0008 will be copied to
C0415/1. A change of C0415/1 sets
C0008 = 255! C0008 255!
A selection under C0117 will be copied to
C0415/2. A change of C0415/2 sets C0415/2 A change of C0415/2 sets
C0117 = 255! C0117 = 255!
LOW LOW LOW LOW
LOW LOW HIGH HIGH
HIGH HIGH LOW LOW
HIGH HIGH
L
