Commissioning
Code table
Code
No. Name
C0245* Selection of
v
comparison value for
MSET1=MACT
(A)
C0250* Torque threshold 1
(MCTRL1-MSET1)
(A)
C0251* Torque threshold 2
(MCTRL1-MSET2)
(A)
C0252* Difference threshold
for MSET1=MACT
(A)
C0253* Difference threshold
for MSET2=MACT
(A)
C0254* Delay MSET1=MACT
(A)
C0255* Delay MSET2=MACT
(A)
C0265 Configuration motor
v v potentiometer potentiometer
Service codes
C0304
...
C0310
C0320 Actual process
controller value
(A)
(PCTRL1-ACT)
C0321 Process controller
setpoint
(A)
(PCTRL1-SET1)
C0322 Process controller
output without
(A)
precontrol
(PCTRL1-OUT)
62
Possible settings
Lenze Selection
0 0 MCTRL1-MSET (C0412/6 or C0047)
1 Value under C0250
0.0 -200.0
0.0 -200.0
0.0 0.0
0.0 0.0
0.000 0.000
0.000 0.000
3
0 Start value = power off
1 Start value = C0010
2 Start value = 0
3 Start value = power off
QSP, if UP/DOWN = LOW
4 Start value = C0010
QSP, if UP/DOWN = LOW
5 Start value = 0
QSP, if UP/DOWN = LOW
EDK82EV903 DE/EN/FR 1.0
{0.1 %} 200.0 Related to rated motor torque
{0.1 %} 200.0 Related to rated motor torque
{0.1 %} 100.0
{0.1 %} 100.0
{0.001 s} 65.000 "Debouncing" of digital output signals
{0.001 s} 65.000 "Debouncing" of digital output signals
IMPORTANT
Selection of a comparison value for setting the
digital output signal MSET1=MACT (torque
threshold 1 = actual torque value)
•
If the difference between MCTRL1 MSET1 If the difference between MCTRL1-MSET1
and MCTRL1-MACT or C0250 is within
C0252:
– MSET1=MACT = HIGH after time set under
C0254
Comparison value for setting the digital output
signal MSET2=MACT (torque threshold 2 =
actual torque value)
•
If the difference between MCTRL1-MSET2
and MCTRL1-MACT is within C0253:
– MSET2=MACT = HIGH after time set under
C0255
MSET1=MACT
•
Sets MSET1=MACT = HIGH if the following
still applies after time set:
– Difference between MCTRL1-MSET1 and
MCTRL1-MACT or C0250 is within the
threshold under C0252
•
Transition HIGH ð LOW without delay
MSET2=MACT
•
Sets MSET2=MACT = HIGH if the following
still applies after time set:
– Difference between MCTRL1-MSET2 and
MCTRL1-MACT is within values set under
C0253
•
Transition HIGH ð LOW without delay
•
Start value: output frequency which is
approached with Tir (C0012) when the mains approached with Tir (C0012) when the mains
is switched on and the motor potentiometer is switched on and the motor potentiometer
is activated:
– "Power off" = act. value if mains is off "P ff" t l if i
– "C0010": min. output frequency from
C0010 C0010
– "0" = output frequency 0 Hz
•
C0265 C0265 = 3, 4, 5: 3, 4, 5:
– QSP reduces the motor potentiometer
along the QSP ramp (C0105)
Modifications only by Lenze Service! o o o y y
Only display
Only display
Only display
