Code
No. Name
C0105 Deceleration time
quick stop (QSP)
C0106 Holding time for
automatic
DC-injection brake
(Auto DCB)
C0107 Holding time DC
injection brake (DCB)
C0108* Gain analog output
X3/62 (AOUT1-GAIN)
C0109* Offset analog output
X3/62
(AOUT1-OFFSET)
L
Possible settings
Lenze Selection
5.00 0.00
0.50 0.00
= auto DCB not active
999.00 1.00
128 0
0.00 -10.00
EDK82EV903 DE/EN/FR 1.0
Commissioning
{0.02 s} 1300.00 Quick stop (QSP) decelerates the drive to
{0.01 s} 999.00
= ∞
{0.01 s} 999.00
= ∞
{1} 255 Standard I/O: C0108 and C0420 are the same
{0.01 V} 10.00 Standard I/O: C0109 and C0422 are the same
Code table
IMPORTANT
standstill according to the ramp set under
C0105. If the output frequency falls below the
threshold under C0019, the DCB will be
activated
Holding time, if DC-injection brake is activated
because the value falls below the setting under
C0019.
Holding time, if DC-injection brakes are
activated via an external terminal or control
word.
Application I/O: C0108 and C0420/1 are the
same
Application I/O: C0109 and C0422/1 are the
same
53
