The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL
DANGER
WARNING
CAUTION
CAUTION
SERVICE
Servicing requires extreme care and knowledge
and should be performed only by a qualified service
technician. For service we suggest you return the product
to your nearest AUTHORISED SERVICE CENTRE for
repair. When servicing, use only identical replacement
parts.
WARNING
To avoid serious personal injury, do not attempt
to use this product until you read thoroughly and
completely understood the operator's manual.
Save this operator 's manual and review
frequently for safe operation and instructing
others who may use this product.
:$51,1*
Observe all normal safety precautions related to
avoiding electrical shock.
SAVE THESE INSTRUCTIONS
DESCRIPTION
Fig. 1
1. Chain Brake
2. Front Handle
3. Oil Tank Cap
4. Safety Lock-off Button
5. Rear Handle
6. Live tool indicator™
7. Switch Trigger
8. Oil Tank Sight Gauge
English (Original instructions)
SYMBOLS
Indicates an imminently hazardous situation, which, if not avoided, will result
in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, could result
in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, may result
in minor or moderate injury.
(Without Safety Alert Symbol) Indicates a situation that may result in property
damage.
16
MEANING
9. Chain Tension Adjust Knob
10. Sprocket Cover
11. Knob w/nut
12. Chain Bar
13. Saw Chain
Fig. 2
14. Safety Lock-off Button
15. Spike
16. Chain Cover
Fig. 3
17. Sprocket
18. Chain Tension Bolt
19. Bar Guide
20. Oil Outlet
Fig. 5
21. Bar Groove
22. Chain Drive Links
23. Cutter
Fig. 9
24. Felling direction
25. Danger Zone
26. Escape route
Fig.10
27. Direction of fall
28. Notch
29. Felling back cut
30. Hinge
Fig.11
31. Limb cut
32. Keep work off ground leave support limbs until log
is cut
Fig.12
