CHAIN & BAR INFORMATION
Model
RCS1835
RCS2040
Note &KDLQ PXVW EH ¿WWHG ZLWK EDU DFFRUGLQJ WR DERYH FRPELQDWLRQV

SPECIAL PRODUCT FEATURES

„
The product is using a special safety wrap-spring
chain break mechanism to stop the chain within one
tenth of a second if the chainbrake is engaged or the
trigger is released.
„
The saw chain's safety drive links are designed to
reduce the risk of kickback.
„
Large chain brake element. In case of a "kickback,
the chain brake is pushed forward" by the back of the
operator's hand and trips the quick brake of the chain
saw.
„
The lock-off Switch with lock to protect against
unintentional start of the chain saw.
„
The unique Ryobi Live tool indicator™ indicate the
good connection with the power supply.
COMMISSIONING
Assembling the chain bar and saw chain
Pull the mains plug out of the socket. Wear
protective gloves.
„
Unscrew the knob w/nut and remove the sprocket
cover. (Fig. 3)
„
The saw chain should face in the direction of chain
rotation. If they face backwards, turn the loop over.
(Fig. 4)
„
Place the chain drive links into the bar groove. (Fig.
5)
„
Position the chain so there is a loop at the back of the
bar.
„
Hold the chain in position on the bar and place the
loop around the sprocket and make sure it is correctly
mounted. (Fig.6)
English (Original instructions)
Chain
Carlton N1C-BL-52E SK B
Oregon 91PJ052X
Oregon 91PJ052X
Tri-link JL9d-3*52
Carlton N1C-BL-56E SK B
Oregon 91PJ056X
Tri-link JL9d-3 x 56
Bar
Carlton 14-10W-MHC UNB Y
Oregon 140SDEA041
Carlton 14-10W-MHC UNB Y
Tri-link DCR14B-050-3/8LP-52-B
Carlton 16-10W-N156-MHC
Oregon 160SDEA041
Tri-link DCR16C-050-Y56LD
„
Swing the chain tension adjust knob, turn the chain
tensioning bolt clockwise until the saw chain is
correctly tensioned. While the bolt is being tightened,
the chain bar must then be pushed upwards, check
chain tension again, do not tension the chain too
tightly (Fig. 7)
„
Replace the sprocket cover on top and tighten gently
with the knob w/nut.
1RWH the saw chain is correctly tensioned if, in the
middle of the cutter, it can be lifted 3mm to 4mm from the
cutter upper edge. Starting the saw again with a new saw
chain, allow it to run in for 2~3 minutes.
:$51,1*
After the run-in time, check the chain tension and
retighten the chain if necessary.
Chain&Bar lubricant
The chain saws are delivered without any oil in the
oiltank. Prior to initial operation of the machine, the oil
tank must be filled with lubricating oil.
Ryobi bar and chain lubricant permits chain saw
operation at temperatures as low as -15°C.
To refill the chain & bar lubricant the cap on top of the
oiltank needs to be removed. When filling the oil in,
ensure that no dirt gets into the oil tank. The oil level can
be monitored at the oil sight gauge. One filling of the oil
tank (capacity 0.2l) is sufficient for 25~40 minutes chain
saw operation.
Checking chain lubrication
If the saw chain is running dry (i.e. without lubricant), the
cutter and saw chain can be damaged. It is therefore
essential to check the oil level in the oil sight gauge
frequently and every time before starting to use the chain
saw.
