Blackmagic Design Desktop Video Manuel D'installation Et D'utilisation page 47

To configure the audio output on Mac OS:
1 Open the Mac OS 'system preferences' and click on the 'sound' icon.
2 Click on the 'output' tab and select 'Blackmagic Audio' for the sound output.
TIP You can also monitor audio via your Desktop Video hardware.
Playback
1 Import some clips in to your new project.
2 You can now use the Final Cut Pro timeline on your computer monitor and view the
video preview on the monitor or TV connected to the output of your Blackmagic Design
video hardware.
Capturing Video and Audio
You can use Blackmagic Media Express to capture video and audio with your Blackmagic
Design video hardware. Once you have captured the clips, you can import them into Final Cut
Pro for editing.
When capturing clips with Media Express, make sure you choose one of the video formats that
is also supported by Final Cut Pro. For example, Apple ProRes 4444 XQ, ProRes 4444, ProRes
422 HQ, ProRes 422, ProRes 422 LT or uncompressed 10-bit 4:2:2.
Editing to Tape
Once you have completed a project in Final Cut Pro, you can render the project to a
movie file and then use Blackmagic Media Express to master the movie to tape with your
Blackmagic Design video hardware.
1 Select your clips from the timeline in Final Cut Pro.
2 Go to file>share>export file and the 'export file' window opens.
3 Click 'settings' and select your desired video codec from the dropdown menu.
4 Click 'next...' and select a location for your movie and then click 'save'.
5 Open Media Express and import the clip that was exported from Final Cut Pro.
6 Refer to the Blackmagic Media Express section of this manual for 'Editing video
and audio files to tape'.
Using your Favorite 3rd Party Software 47
