Click on an icon to set your video input connection.
Use XLR Timecode
Select this setting to read timecode from the XLR input instead of the SDI stream.
Enable the checkbox to capture timecode from the dedicated XLR input
Analog Video Input Levels
Drag the 'video' and 'chroma' sliders to adjust the analog video input levels for component
or composite video. Dragging the video slider affects the luma gain and the chroma sliders
decrease or increase the color saturation. When using component video, you can adjust the
Cb and Cr values independently. Click the 'link' icon to connect them if you want to adjust them
simultaneously.
Video Output
Select the video standard and adjust other settings for your video output.
General
Default Video Standard
‚
To use broadcast monitoring with Final Cut Pro, set the output format to match your Final
Cut Pro project.
‚ When Paused
Click to select whether to display a full frame or a single field on the output when paused.
Video Playback
‚
Click to select whether to display a freeze frame or black output when not playing.
‚ During Capture
Click to select whether the video output displays the playback video or input video during
capture. If you select the 'video output displays playback video' option, then your selection
in the 'video playback' section will dictate what is displayed on your output. If you select
the 'video output displays input video' option, then the input video will be displayed on
your outputs.
