COVERS AND FUEL TANK
2
a
1
2-6

COVERS AND FUEL TANK REMOVAL

WARNING
Do not smoke, and keep away form open
flames, sparks, or any other source of fire
when handling or in the vicinity of fuel.
1. Remove:
9 Rear cover 1
9 Side cover right
9 Side cover left
9 Fuel tank cap
9 Rear cover 2
2. Remove:
9 Recoil starter handle 1
TIP
Tie a knot b in the starter rope 2 in front of
the starter handle 1 to prevent the starter
rope from entering the starter case, and then
untie the knot a on the starter handle side to
remove.
3. Remove:
9 Fuel cock knob
9 Ground (earth) lead
9 Control unit cover
9 Front cover
WARNING
Take care not to rotate the fuel cock knob
to the "ON" position when you remove it.
4. Drain the fuel from the fuel tank com-
pletely.
5. Remove:
9 Fuel hose
9 Fuel tank
