Tabletop mounting
1
Fig. 4: Preparations for table mounting
Opening
1
Fixing element
2
On the underside of the mounting plate, the boreholes for countertop
mounting ( Fig. 4 ,
Only fixing elements
1. Turn the mounting plate over
2. Push the fixing elements from the rear
and allow them to engage.
3. Turn the mounting plate over again and hold it against the required mounting
position.
4. Using the mounting plate as a template, mark the required boreholes
sharp pencil.
5. Drill the holes.
6. When mounting the plate on a stone surface, use suitable dowels and screws to
fix the mounting plate in place.
For table mounting, secure the mounting plate using Ø 5 mm screws.
7. Place the pump onto the mounting plate.
8. Push the pump to the back of the mounting plate until the fixing bracket
audibly clicks into place.
9.
To remove the pump from the mounting plate again,
the fixing bracket.
10. Attach the connecting lines (hydraulic and electric):
Ä Chapter 6.2.1 'Hydraulic installation' on page 36
Ä Chapter 6.2.2 'Electrical installation' on page 44 .
3
2
4
Borehole
3
Fixing bracket
4
) are marked with a 1.
1
with the number 1 may be used for table mounting.
2
into the four openings marked 1
2
33
Assembly and connection
push down on
4
