6.3 Setting
8027506.1OT5/2025-03-18 | SICK
Subject to change without notice
Dimensions in mm (inch)
6
(0.24)
4
(0.16)
2
(0.08)
0
–2
(–0.08)
–4
(–0.16)
–6
0 20 40 60
(–0.24)
(0.79) (1.57) (2.36)
Distance in mm (inch)
Recommended sensing range for
the best performance
A Sensing range min. in mm
B Sensing range max. in mm
C Field of view
D Adjustable switching threshold for background suppression
E Sensing range indicator
F Teach-Turn adjustment
blue Recommended sensing range for the best performance
Check the function as described in
behave as described in see table 4, page
WTB4F-xxxxxx2
The sensing range is adjusted by pressing the teach-in button (approx. 1-3 sec.).
Depending on the requirements, the potentiometer can be used for fine-tuning (without
pressing the teach-in button).
Clockwise rotation: Sensing range increased.
Counterclockwise rotation: Sensing range reduced.
The sensing range can also be adjusted using just the potentiometer.
OPERATING INSTRUCTIONS
80 100 10
(3.15) (3.94) (0.39)
see table 4, page 26. If the digital output fails to
26, check the application conditions.
O P E R A T I N G I N S T R U C T I O N S | W4F MultiPulse
50 100
(1.97) (3.94)
29
