m Warning! This power tool generates an electro-
magnetic field during operation. This field can impair
active or passive medical implants under certain cir-
cumstances. In order to prevent the risk of serious
or deadly injuries, we recommend that persons with
medical implants consult with their physician and the
manufacturer of the medical implant prior to operating
the power tool.
Residual risks
The machine has been built according to the state-of-
the-art and the recognised technical safety require-
ments. However, individual residual risks can arise
during operation.
• Danger of injury for fingers and hands from the split-
ting tool in the event of improper guiding or support
of the wood.
• Injuries due to the workpiece being ejected at high
speed due to improper holding or guiding.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Switch off the device and pull out the mains plug be-
fore carrying out any setting or maintenance work.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the "Safety In-
structions" and the "Intended Use" together with the
operating manual as a whole are observed.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet. Use the tool that is recommended
in this operating manual.
• This is how to ensure that your machine provides
optimum performance
• Keep your hands away from the working area when
the machine is in operation.
7.
Technical data
Compact 10t
Dimensions D/W/H mm
Swivel table height mm
Working height mm
Min./max. wood length cm
Min./max. wood diameter cm
Splitting force max. t*
42 | GB
Subject to technical changes!
* The maximum achievable splitting force is dependent
on the resistance of the log and can differ due to varia-
ble contributing factors on the hydraulic system.
** Operating mode S6 40%, uninterrupted periodic op-
eration with intermittent load. The mode comprises of
a start-up period, a time with constant load and an idle
time. The operating time is 10 mins, the relative duty
cycle is 40% of the operating time.
Noise
The noise levels have been determined in accordance
with EN 62841.
Excessive noise can result in a loss of hearing.
The specified noise emission values have been meas-
ured in accordance with a standardised test procedure
and can be used to compare one power tool with another.
830/930/1020
The specified device emissions values can also be
390
used for an initial estimation of the load.
920
Warning:
75/107
• The noise emission values can vary from the spec-
8/38
10
400 V
230 V
www.scheppach.com
Forward stroke speed cm/s
Reverse stroke speed cm/s
Oil quantity ml
Weight kg
Drive
Mains power connection 400 V
3N~/50Hz/ 230 V 1~/50Hz
Rated input P1 W
Power output P2 kW
Operating mode
Motor speed rpm
Motor protection
Phase inverter
Sound pressure level L
pA
Uncertainty K
pA
Sound power level L
WA
Uncertainty K
WA
ified values during the actual use of the power tool,
depending on the type and the manner in which the
electric tool is used, and in particular the type of
workpiece being processed.
5.5
3
15.4
14
4800
134
400/50
230/50
3500
3150
2500
2300
S6 40% **
2800
yes
at 400V
77.4 dB
3 dB
93.6 dB
3 dB
