Note
The splitting column (1) must be retracted before the oil
change, the device must be level.
1.
Position a suitable collecting container with min.
7 litre volume.
2.
Unscrew the bleeder screw (23).
3.
Remove the oil drain screw (25) with a 24mm
open-ended spanner to let the oil drain out.
4.
Screw the oil drain screw (25) back in.
5.
Fill up with new hydraulic oil (approx. 4800 ml).
6.
Screw the bleeder screw (23) back in.
7.
Check the oil level as described in section 10.2.
8.
Dispose of the used oil properly at a local used oil
collection point.
The time intervals cited here relate to normal operating
conditions. If the device is subjected to heavier loads,
these times must be reduced accordingly.
Service information
With this product, it is necessary to note that the follow-
ing parts are subject to natural or usage-related wear,
or that the following parts are required as consuma-
bles.
Wearing parts*: Riving knife, hydraulic oil and riving
knife/spindle guides
* may not be included in the scope of delivery!
Spare parts and accessories can be obtained from our
Service Centre. To do this, scan the QR code on the
front page.
13. Storage
Note
Move the splitting column into the bottom position (see
section 11.6).
Store the device and its accessories in a dark, dry and
frost-free place that is inaccessible to children. The
optimum storage temperature is between 5 and 30 ˚C.
Keep the power tool in its original packaging. Cover the
power tool to protect it from dust or moisture. Store the
operating manual with the power tool.
14. Transport
m Attention!
Disconnect the mains plug before transport.
m Attention!
Do not transport the device lying down!
Note
Move the splitting column into the bottom position (see
section 11.6).
14.1 Transport with transport handle (5) (Fig. 19)
The log splitter is equipped with two transport wheels
(11) and a transport handle (5) for easy transport.
1.
In order to transport the device, hold the transport
handle (5) with one hand and tilt the log splitter
slightly with your foot.
2.
The log splitter tilts on the transport wheels (11)
and can thus be moved away.
14.2 Transport by crane (Fig 20)
m Attention!
Never lift by the riving knife!
1.
Attach the transport straps (not included) on both
sides to the upper bracket (15a) of the guard rail
(15) and to the holder of the transport lever (7).
2.
Lift the device up carefully.
15. Electrical connection
The electrical motor installed is connected and
ready for operation. The connection complies with
the applicable VDE and DIN provisions.
The customer's mains connection as well as the
extension cable used must also comply with these
regulations.
Use a portable safety switch (PRCD) if the residual
current protective circuit (RCD) in the mains power
supply is not provided with a rated residual current
of no more than 30 mA.
The mains power connection is protected with a 16
A slow-blow fuse.
Damaged electrical connection cables
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Pressure points, where connection cables are
passed through windows or doors.
• Kinks where the connection cable has been improp-
erly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
www.scheppach.com
GB | 49
