12. Cleaning
Attention!
Pull out the power plug before carrying out any clean-
ing work on the equipment.
We recommend that you clean the equipment imme-
diately after you use it.
Clean the equipment regularly with a damp cloth and
some soft soap. Do not use cleaning agents or sol-
vents; these may be aggressive to the plastic parts in
the equipment. Ensure that no water can get into the
interior of the equipment.
13. Transport
Move the splitter to the transport position beforehand.
See item 9.3, proceed in reverse order.
The log splitter is equipped with two transport wheels
and an additional transport wheel. Use the transport
handle (2) to move the splitter.
14. Storage
Store the device and its accessories in a dark, dry
and frost-proof place that is inaccessible to children.
The optimum storage temperature is between 5 and
30˚C.
Cover the electrical tool in order to protect it from
dust and moisture.
Store the operating manual with the electrical tool.
15. Maintenance
Attention!
Pull out the power plug before carrying out any main-
tenance work on the equipment. Make sure that the
drive shaft is not connected to the traction unit.
When must the oil be changed?
First oil change after 50 operating hours, then every
250 operating hours.
Oil change (fig. 16)
Position the kindling splitter on a slightly raised sur-
face (e.g. euro pallet). Place a sufficiently large con-
tainer (at least 20 litres) under the drain plug on the
splitting column. Open the drain plug and carefully let
the oil run into the container.
Open the filling screw on the top of the splitting col-
umn so the oil can drain more easily. Replace the
drain plug and its seal and tighten it.
Pour in fresh hydraulic oil (Contents: see Technical
data) and check the oil level with the dipstick. After
changing the oil, operate the kindling splitter a few
times without actually splitting.
www.scheppach.com / service@scheppach.com / +(49)-08223-4002-99 / +(49)-08223-4002-58
Warning! Ensure that no debris gets into the oil
container.
Dispose of the used oil in a correct manner at a
public collection facility. It is prohibited to drop
old oil on the ground or to mix it with waste.
We recommend oil from the HLP 32 range.
Hydraulic system
The hydraulic unit is a closed system with oil tank, oil
pump and control valve.
The system is complete when the machine is deliv-
ered, and may not be changed or manipulated.
Connections and repairs
Connections and repairs of electrical equipment may
only be carried out by an electrician.
ATTENTION ! Observe the correct direction of rota-
tion when inserting the saw blade.
Please provide the following information in the event
of any enquiries:
• Type of current for the motor
• Machine data - type plate
• Machine data - type plate
Service information
Please note that the following parts of this product
are subject to normal or natural wear and that the fol-
lowing parts are therefore also required for use as
consumables.
Wear parts*: splitting wedge guides, hydraulic oil,
splitting wedge
* Not necessarily included in the scope of delivery!
16. Disposal and recycling
The equipment is supplied in packaging to
prevent it from being damaged in transit. The
raw materials in this packaging can be re-
used or recycled. The equipment and its ac-
cessories are made of various types of ma-
terial, such as metal and plastic.
Defective components must be disposed of as spe-
cial waste. Ask your dealer or your local council.
GB | 27
