Remaining hazards
The machine has been built using modern tech-
nology in accordance with recognized safety
rules. Some remaining hazards, however, may
still exist.
• The splitting tool can cause injuries to fingers and
hands if the wood is incorrectly guided or support-
ed.
• Thrown pieces can lead to injury if the work piece
is not correctly placed or held.
• Injury through electric current if incorrect electric
connection leads are used.
• Even when all safety measures are taken, some
remaining hazards which are not yet evident may
still be present.
• Remaining hazards can be minimized by following
the safety instructions as well as the instructions in
the chapter Authorized use and in the entire oper-
ating manual.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Release the handle button and switch off the ma-
chine prior to any operations.
• Avoid accidental starts of the machine: Do not
press the start button while inserting the plug into
the socket.
• Use the tools recommended in this manual to ob-
tain the best results from your machine.
• Always keep hands away from the work area when
the machine is running.
7. Technical data
Motor
Input P1
Output P2
Operating mode
Motor speed
Phase inverter
Dimensions D/W/H
1150 x 1050 x 2500 mm
Log length
Power max.
Piston stroke
Forward speed
Return speed
Oil quantity
Weight
Subject to technical changes!
24 | GB
www.scheppach.com / service@scheppach.com / +(49)-08223-4002-99 / +(49)-08223-4002-58
8. Unpacking
Open the packaging and remove the device carefully.
Remove the packaging material as well as the pack-
aging and transport bracing (if available).
Check that the delivery is complete.
Check the device and accessory parts for transport
damage. In case of complaints the dealer must be
informed immediately. Subsequent complaints will
not be accepted.
If possible, store the packaging until the warranty pe-
riod has expired. Read the operating manual to make
yourself familiar with the device prior to using it.
Only use original parts for accessories as well as for
wearing and spare parts. Spare parts are available
from your specialized dealer.
Specify our part numbers as well as the type and year
of construction of the device in your orders.
m ATTENTION
The device and packaging materials are not toys!
Children must not be allowed to play with plas-
tic bags, film and small parts! There is a risk of
swallowing and suffocation!
9. Attachment / Before starting the
9.1 Attaching the wheel axle
Mount the wheel axle on the designated spot at the
lower rear end of the splitter and use two brackets
and nuts to tighten it.
400V / 50Hz
9.2 Attaching the wheels
4500 W
3500 W
First, place a washer on each side of the wheel axle,
S6 40%
then attach the wheels and secure them with another
washer and a cotter pin.
1400 1/min
yes
9.3 Putting the splitter into the work position
1100 mm
Connect the splitter to the mains power. Be aware of
16 t
the motor's direction of rotation. Lower both control
handles until the cylinder engages with the guide.
948 mm
Insert the two L-pins (C) to secure the cylinder on
14,2 cm/s
the kindling splitter. Secure the L-pins in the spring
6,4 cm/s
tabs. Then bring the splitting blade to the top position
18 l
and remove the support. You must store the support
256 kg
safely because it is needed every time the splitter is
transported.
9.4 Attaching the supporting arm (12)
Secure the supporting arm with a hexagon bolt
M10x40, two washers and a nut.
equipment
(enclosed accessories bag a) (fig. 3)
(enclosed accessories bag b) (fig. 4)
(enclosed accessories bag c) (fig. 5 + 6)
(enclosed accessories bag d) (fig. 7)
