9.5 Attaching the hook (D)
(enclosed accessories bag e) (fig. 8)
Attach the hook on the frame with 2 hexagon bolts
and 2 nuts.
9.6 Attaching the log lifter
(enclosed accessories bag f) (fig. 9)
Attach the log lifter on the fixing bracket with 1 hexa-
gon bolt M16x100.
Hook the chain onto the splitting blade.
9.7 Attaching the additional wheel (fig. 12)
Mount the transport wheel as shown in Fig. 12. Use
the locking pin to attach the wheel either to the upper
or the lower hole.
9.8 Moving the transport handle (2) to the trans-
port position (fig. 13)
The transport handle is already pre-assembled on
the splitter and is fixed in working position. Release
the tension lever (1) and move the transport handle
(2) down until you can insert the tension lever into the
next hole and fix the transport handle in the position
(3).
m IMPORTANT!
You must fully assemble the appliance before using it
for the first time!
10. Initial operation
Make sure the machine is completely and expertly
assembled. Check before every use:
• The connection cables for any defective spots
(cracks, cuts etc.).
• The machine for any possible damage.
• The firm seat of all bolts.
• The hydraulic system for leakage.
• The oil level.
Checking the oil level
The hydraulic unit is a closed system with oil tank,
oil pump and control valve. Check the oil level regu-
larly before every use. Too low an oil level can dam-
age the oil pump. The level of oil must be checked
when the riving knife is pulled back. If the oil level is
at the lower notch, then the oil level is at a minimum.
Should this be the case, oil must be immediately
added. The upper notch indicates the maximum oil
level. The machine must be on level ground. Screw
in the oil dipstick fully, to measure the oil level.
www.scheppach.com / service@scheppach.com / +(49)-08223-4002-99 / +(49)-08223-4002-58
E- Motor
Check the running direction of the motor. If the split-
ting arm is not in the top position, bring the splitting
blade in the top position, using the return bracket or
handles. If the splitting arm is already in the top posi-
tion, activate the splitting mechanism by moving both
levers down. This will move the splitting arm down. If
the splitting blade does not move despite activation of
the handles or return bracket, immediately turn off the
machine. Turn the pole reversing unit in the plug-in
module (Fig. 11 + 12) to change the rotational direc-
tion of the motor.
Never let the motor run in the wrong direction!
This will inevitably destroy the pump system and
no warranty claim can be made.
Functional test
Test the function before every use.
Action:
Result:
Push both handles
Splitting knife goes down
towards below.
to approx. 20 cm above
the table.
Let one handle loose,
Splitting knife stops in the
then the other.
desired position.
Push both handles
Splitting knife returns to
towards up
upper position
Warning!
Loosen the filling screw (fig. 17) before commis-
sioning.
Never forget to loosen the filling screw! Other-
wise, the air in the system will constantly be com-
pressed and decompressed with the result that
the seals of the hydraulic circuit will be destroyed
and the wood splitter can no longer be used. In
this case, the seller and the manufacturer will not
be liable to warranty services.
Switching on and off (11)
Press the green button for switching on.
Press the red button for switching off.
Note: Check the function of the ON/OFF unit before
every use by switching on and off once.
Restarting safety in case of current interruption
(no-volt release).
In case of current failure, inadvertent pulling of the
plug, or a defective fuse, the machine is switched off
automatically. For switching on again, press anew
the green button of the switch unit.
Using the safety arm (fig. 14)
The safety arm can be set at different height posi-
tions, depending on the length of the wood.
GB | 25
