Loosen the transport lever (7) of the trunk lifter so
that the lifting tube can move freely.
4.
Lower the splitting wedge (4) until the log lifter (9)
rests completely on the ground.
5.
Roll the log onto the trunk lifter (9) and the base
plate (13). The log must lie between the two fixings
of the trunk lifter (9).
6.
Actuate the stop lever (19).
7.
Switch the motor (21) on (see section 10.5).
8.
Slowly loosen the stop lever (19).
9.
The trunk lifter (9) moves upwards and positions
the log on the base plate (13).
10. Make sure that the log is placed centrally to the
splitting wedge (4).
11. Split the split material. Proceed as described in
section 11.2. 2.
11.2.2 Splitting long logs (Fig. 1, 16, 17)
1.
Swivel the swivel table (14) to the side with your
hand or foot.
2.
Place the log straight on the base plate (13).
3.
Hold the log with the two retaining claws (18) on
the operating arms (6). Make sure that the log is
placed centrally to the splitting wedge (4).
4.
Press both operating levers (16) down simultane-
ously.
5.
Move the operating arms (6) approx. 2 cm away
from the log as soon as the splitting wedge (4)
penetrates. This prevents damage to the retaining
claws (16).
6.
Drive the splitting wedge (4) down until the log is
split.
7.
If the log has not been completely split during the
first splitting stroke, proceed as described in sec-
tion 11.4.
11.3 Starting position trunk lifter (9) (Fig. 18, 18a)
Note
This is used as a second guard arm when not using
the trunk lifter.
1.
Put the trunk lifter (9) in the resting position.
2.
Secure the trunk lifter (9) with the transport lever
(7).
11.4 Removing a jammed log (Fig. 1, 16, 17)
Note:
Split through jammed wood using the swivel ta-
ble, knock it out against the splitting direction or
remove it by moving the splitting wedge upwards.
m ATTENTION!
Danger of injury!
The swivel table must engage in the locking hook!
m ATTENTION!
Danger of injury!
There is a danger of knotty logs becoming jammed dur-
ing the splitting process. Please note that the wood is
under a lot of tension when it is removed and parts of
your body can be crushed in the split crack.
- Do not reach into the log splitter when it is running.
- Do not put any objects into the log splitter while it is
running (e.g. hammer or similar).
1.
If the log is not completely split during the first
splitting stroke, carefully move the splitting wedge
(4) with the log to the upper position using the two
operating levers (16).
2.
Swivel in the swivel table (14) by foot until the lock-
ing hook (10) engages.
3.
Now carry out a second splitting stroke until the
log is completely split.
4.
Remove the log and swivel the swivel table (14)
away with your foot.
11.5 Restart protection in the event of a power fail-
ure (zero voltage trigger)
In the event of a power failure, unintentional unplugging
of the plug or a defective fuse, the device switches off
automatically.
To switch on again, proceed as described in section
10.5.
11.6 End of work (Fig. 1, 12, 18)
1.
Move the splitting column (1) to the bottom posi-
tion.
Release a control lever (16).
2.
3.
Actuate the stop lever (19).
4.
Switch off the motor (21) (see section 10.5) , and
disconnect the mains plug.
5.
Swivel in the swivel table (11) by foot until the lock-
ing hook (7) engages.
6.
Close the bleed screw (23).
7.
Protect the device from moisture!
8.
Observe the general maintenance information.
