SECTIoN 3
WarNINg
3.5

Primary Input Connections

The ESP-101 460V consoles are equipped
with approximately 15 ft. of 4-conductor
input power cable for 3 phase connection.
See specification section or rating plate.
a. 460V
B. 380-400V
ElECTrIC ShoCK CaN KIll! PrECauTIoNarY MEaSurES ShoulD
BE TaKEN To ProVIDE MaxIMuM ProTECTIoN agaINST ElECTrI-
Cal ShoCK. BE SurE ThaT all PoWEr IS off BY oPENINg ThE lINE
(Wall) DISCoNNECT SWITCh aND BY uNPluggINg ThE PoWEr
CorD To ThE uNIT WhEN CoNNECTIoNS arE MaDE INSIDE of ThE
PoWEr SourCE.
PHASE
L1
L2
L3
GND
PRIMARY INPUT
POWER CABLE
figure 3-1. Input Connections
STaNDarD uNITS
(NoN-CE)
3
Black
Red
White
Green
CUSTOMER FUSED LINE DISCONNECT SWITCH
GND
L3
L2
L1
16
INSTallaTIoN
CE uNITS
(EuroPE)
PHASE 3
L1 Brown
L2 Black
L3 Gray
GND Green/Yel
(See Table 3-1)
