Stihl FSA 200.0 R Notice D'emploi page 40

English
26.2 STIHL AP Series Battery
Approved charger types: STIHL AL 101, AL 301,
AL 301-4, AL 501.
– Battery technology: Lithium-Ion
– Voltage: 36 V
– Rated capacity in Ah
– Stored energy in Wh
– Weight in kg: See rating plate
®
– Bluetooth interface (only for batteries with
)
– Data transmission protocol: Bluetooth
The mobile receiving devices must be com‐
patible with Bluetooth
support the Generic Access Profile (GAP).
– Frequency band: ISM band 2.4 GHz
– Radiated maximum transmission power:
1 mW
®
– Bluetooth signal range: maximum 33 ft.
(10 m). The signal range may vary depend‐
ing on ambient conditions and the perform‐
ance of the designated receiving device,
i.e., smartphone or tablet. The Bluetooth
range may be significantly limited when the
signal is transmitted through metallic barri‐
ers (e.g., walls, shelving units, etc.) or near
strong electromagnetic fields.
– Minimum mobile terminal device (e.g., tab‐
let, smartphone) system requirements:
Android or iOS (in current version or higher)
For a complete list of approximate charging
times, see www.stihl.com/charging-times.
For a complete list of approximate battery run‐
times, see www.stihl.com/battery-life.
®
Bluetooth
®
The Bluetooth word mark and logos are regis‐
tered trademarks owned by Bluetooth SIG, Inc.
These word mark/logos are used by STIHL
under license.
If the battery is equipped with a Bluetooth
face, local operating restrictions (in aircraft or
hospitals, for example) must be observed.
3
Rated capacity calculated pursuant to IEC 61960. Usable energy available to the operator will be
less.
4
The battery is marked with its stored energy as provided by the cell manufacturer. Usable energy
available to the operator will be less.
40
3
: See rating plate
4
: See rating plate
®
®
Low Energy 5.0 and
®
inter‐
Other Trademarks
Apple and the Apple logo are trademarks of
Apple Inc., registered in the U.S. and other coun‐
tries.
App Store is a service mark of Apple Inc.
Google Play and the Google Play logo are trade‐
marks of Google Inc.
26.3 Symbols on the Power Tool,
Deflector and Battery
5.1.
Symbol Explanation
V Volt
Hz Hertz
A Ampere
Ah Ampere hour
W Watt
Wh Watt hour
AC Alternating current
IPX4 Protection against spraying or splash‐
®
ing water from all directions.
Symbol on the deflector showing
proper direction of rotation for the cut‐
ting attachment.
Push the retaining button forward to switch
the trimmer / brushcutter on and to set the
power levels.
Maximum allowable diameter of the
cutting attachment
Maximum speed of the cutting attachment.
Unit: rpm (1/min)
Number of cells and stored energy accord‐
ing to cell manufacturer's specification.
Usable energy will be less.
STIHL products must not be disposed of in
the household trash, but only in accord‐
ance with local, state and federal laws and
regulations and as provided in this manual,
29.1.
The RBRC seal indicates that STIHL has
prepaid for battery recycling
The battery is equipped with Blue‐
tooth
STIHL connected App.
26 Specifications
®
and can be connected with the
0458-041-8201-A
