Stihl FSA 200.0 R Notice D'emploi page 37

24 Inspection and Maintenance
2
1 1
► Press both tabs (1) and remove the cover (2).
► Press down on the spool (3), turn it clockwise
to release the spool and pull up to remove it.
► Remove the remaining trimmer line (4) and
dispose of it.
► If you use trimmer line with a diameter of
0.095 in. (2.4 mm), cut a 33 ft. m (10 m) length
of nylon line from the reel and then cut it in
half, making two 16.5 ft. (5 m) lengths.
5
► Insert the first 16.5 ft. (5 m) length of line into
the eyelet (5) nearest the notches (6) until it
stops.
► Wind the trimmer line firmly and evenly in the
direction of the arrow on the bottom of the
mowing head.
► Hook the end of the trimmer line into one of
the notches (6).
7
► Repeat the winding process with the second
16.5 ft. (5 m) length of trimmer line using the
other eyelet (7) and notch (6).
0458-041-8201-A
6
3
9
4
3
8
► Fit the spool (3) into the mowing head (8).
► Press and turn the spool until one of the
notches (6) is aligned with one of the eye‐
lets (9) and one of the spool tabs is held in
place by a tab in the mowing head.
► Put the ends of the trimmer line (12) through
the eyelets (9).
► Fit the cover (2) on the mowing head. Align
the tabs (1) of the cover with the openings (11)
in the mowing head.
6
Both tabs should click audibly into place.
► Pull on the line until the spool moves up
slightly.
NOTICE
■ Overly long trimmer line increases the load on
the motor and reduces its operating speed.
This may result in overheating and damage to
important components.
24.5 Sharpening and Balancing a
Metal Cutting Attachment
6
WARNING
■ Never use a dull or damaged metal cutting
attachment. Working with a dull blade leads to
increased physical strain, increased vibration
load, unsatisfactory cutting results and
increased wear, which can result in loss of
control and injury to the operator or bystand‐
ers. A damaged cutting attachment may
vibrate, crack, break or come off the trimmer /
brushcutter, which may result in serious or
fatal injury or property damage. Make sure the
cutting attachment is sharp and in good condi‐
tion before starting work.
1
12
11
Watch a video on how to replace trim‐
mer line on an AutoCut 25-2 mowing
head at bit.ly/Autocut25-2. Click here
or type this address into your browser.
English
2
1
12
9
8
37
