2) GENERAL INFORMATION

The RIGEL 6 control panel comes with standard factory settings. Any change
must be made using the programmer with built-in display or universal handheld
programmer. The Control unit completely supports the EELINK protocol.
Its main features are:
- Check of 1 or 2 single-phase motors tted with thermostat
- Control of 1 or 2 single phase motors
Note: 2 motors of the same type must be used.
- Opening/closing limit switch control inputs, separate for each motor
- Separate inputs for safety devices
- Time band management
- Integrated obstacle detection
- Motor pre-heating with integrated sensor reading
- Adjustable electrodynamic braking
- Approach speed slow-down
- Built-in radio receiver rolling code with transmitter cloning.
The board has a terminal strip of the removable kind to make maintenance
or replacement easier. It comes with a series of prewired jumpers to make the
installer's job on site easier.
The jumpers concern terminals: 41-42, 41-43, 41-44, 41-45, 70-71, 70-72,
70-74, 76-77, 76-79, 81-82, 81-84. If the above-mentioned terminals are
being used, remove the relevant jumpers.
TESTING
The RIGEL 6 panel controls (checks) the run relays, triacs and safety devices (pho-
tocells and edges), before performing each opening and closing cycle.
If there is a malfunction, make sure that the connected devices are working
properly and check the wiring.
ATTENTION! if the leaf is installed in a public area or if an automatic operating
mode is enabled, we recommend a pair of photocells is installed at a height of 5
cm together with another pair at a height of 40-50 cm. Automatic mode means any
control not voluntarily activated by the user (example: TCA function, chrono, etc.)

3) TECHNICAL SPECIFICATIONS

Power supply
Low voltage/mains insulation
Dielectric rigidity
Accessories power supply
AUX 0
AUX 1
AUX 2
Terminal
L
N
GND
10
11
12
14
15
16
AUX 1 - 220-230V~
20
POWERED CONTACT
21
AUX 1 - 220-230V~
22
POWERED CONTACT
23
24
AUX 2 - FREE CONTACT
25
26
AUX 3 - FREE CONTACT
27
28
29
40
41
42
43
44
45
50
51
52
40
- RIGEL 6
INSTALLATION MANUAL
220-230V 50/60Hz(*)
> 2MOhm 500V
mains/LV 3750V~ for 1 minute
24V~ (demand max. 1A)
24V~safe
80W MAX)
NO 220-230V~ (
powered contact
AUX0+
80W MAX)
NO 220-230V~ (
powered contact AUX1+
AUX2=
NO contact
80W MAX
(MAX 220-230V~ 80W)
De nition
LINE
NEUTRAL
Single-phase power supply
EARTH
MOT1 RUN
MOT 1 COM Connection motor 1. Time lag during closing.
MOT1 RUN
MOT2 RUN
Connection motor 2. Time lag during opening.
MOT 2 COM
Note: if "1 MOT. O N. " = 1 do not connect any wires to terminals 14-15-16
MOT2 RUN
AUX 0 con gurable output - Default setting FLASHING LIGHT.
MONOSTABLE RADIO CHANNEL/ SCA GATE OPEN LIGHT/ COURTESY LIGHT command/ ZONE LIGHT command/ STAIR LIGHT/
GATE OPEN ALARM/ FLASHING LIGHT/ SOLENOID LATCH/ MAGNETIC LOCK/ MAINTENANCE/ FLASHING LIGHT AND MAINTE-
NANCE / GATE STATUS / BISTABLE RADIO CHANNEL / TIMED RADIO CHANNEL.
Refer to "AUX output con guration" table.
AUX 1 con gurable output - Default setting ZONE LIGHT Output.
MONOSTABLE RADIO CHANNEL/ SCA GATE OPEN LIGHT/ COURTESY LIGHT command/ ZONE LIGHT command/ STAIR LIGHT/
GATE OPEN ALARM/ FLASHING LIGHT/ SOLENOID LATCH/ MAGNETIC LOCK/ MAINTENANCE/ FLASHING LIGHT AND MAINTE-
NANCE / GATE STATUS / BISTABLE RADIO CHANNEL / TIMED RADIO CHANNEL.
Refer to "AUX output con guration" table.
AUX 2 con gurable output - Default setting SCA GATE OPEN LIGHT Output.
MONOSTABLE RADIO CHANNEL/ SCA GATE OPEN LIGHT/ COURTESY LIGHT command/ ZONE LIGHT command/ STAIR LIGHT/
GATE OPEN ALARM/ FLASHING LIGHT/ SOLENOID LATCH/ MAGNETIC LOCK/ MAINTENANCE/ FLASHING LIGHT AND MAINTE-
(N.O.)
NANCE / GATE STATUS / BISTABLE RADIO CHANNEL / TIMED RADIO CHANNEL.
Refer to "AUX output con guration" table.
AUX 3 con gurable output - Default setting MONOSTABLE RADIO CHANNEL Output.
MONOSTABLE RADIO CHANNEL/ SCA GATE OPEN LIGHT/ COURTESY LIGHT command/ ZONE LIGHT command/ STAIR LIGHT/
GATE OPEN ALARM/ FLASHING LIGHT/ SOLENOID LATCH/ MAGNETIC LOCK/ MAINTENANCE/ FLASHING LIGHT AND MAINTE-
(N.O.)
NANCE / GATE STATUS / BISTABLE RADIO CHANNEL / TIMED RADIO CHANNEL.
Refer to "AUX output con guration" table.
Type of lock logic= 0 - 12V
Output activated with a pulse each time gate is opened or closed
LOCK 12V
Type of lock logic= 1 - 12V
Output activated when gate is closed or closing
Not used
+ REF SWE Limit switch common
SWC 1 Motor 1 closing limit switch SWC1 (N.C.).
SWO 1 Motor 1 opening limit switch SWO1 (N.C.).
SWC 2 Motor 2 closing limit switch SWC2 (N.C.).
SWO 2 Motor 2 opening limit switch SWO2 (N.C.).
24V-
Accessories power supply output.
24V+
Tested safety device power supply output (photocell transmitter and safety edge transmitter).
24 Vsafe+
Output active only during operating cycle.
AUX 3
LOCK
Dimensions
Fuses
N° of combinations
Max.n° of transmitters that
can be memorized
(*other voltages to order)
Use cycle continuous
Operating
-20°C/+50°C
temperature range
Maximum motor
2x375 W
power 220-230V
1x750 W
Maximum motor
2x320 W
power110-120V
1x390 W
M1+M2+AUX0+AUX1+AUX2+AUX3+LOCK= 1300W MAX T=+50°C
Usable transmitter versions:
All ROLLING CODE transmitters compatible with
4) TUBE ARRANGEMENT Fi g. A
5) TERMINAL BOARD WIRING Fig. C
WARNINGS - When performing wiring and installation, refer to the standards in
force and, whatever the case, apply good practice principles.
Wires carrying di erent voltages must be kept physically separate from each other,
or they must be suitably insulated with at least 1mm of additional insulation.
Wires must be secured with additional fastening near the terminals, using devices
such as cable clamps.
All connecting cables must be kept far enough away from the dissipater.
Description
220-230V 50/60Hz(*)
solenoid latch output.
magnetic lock output.
NO contact (Max 24V~)
Output for 12V sole-
noid lock:
see Fig. B
see Fig. C
4 billion
63
continuous 1 min. ON/
2 min. OFF
-20°C/+55°C -20°C/+50°C
2x250 W 2x650 W
1x500 W 1x750 W
(MODEL ECB)
10W MAX
10W MAX
1 min. ON/
2 min. OFF
-20°C/+55°C
2x500 W
1x750 W
