BFT RIGEL 6 Instructions D'installation page 48

Logic De nition
Con guration of
EXPI2 input
on input-output
EXPI2
expansion board.
Con guration of
EXPO2 output
on input-output
EXPO1
expansion board
Con guration of
EXPO2 output
on input-output
EXPO2
expansion board
TRAFFIC LIGHT
Tra c light pre-
PREFLASHING
TRAFFIC LIGHT
RED LAMP Steadily lit red light
ALWAYS ON
*
Only active on FW > 1.12
CH logic= 0 - Control con gured as Start E. Operation according to STEP-BY-STEP MOV. logic. External start for tra c light control.
CH logic= 1 - Control con gured as Start I. Operation according to STEP-BY-STEP MOV. logic. Internal start for tra c light control.
CH logic= 2 - Control con gured as Open.
The command causes the leaves to open.
CH logic= 3 - Control con gured as Closed.
The command causes the leaves to close.
CH logic= 4 - Control con gured as Ped.
The command causes the leaf to open to the pedestrian (partial) opening position. Operation according to STEP-BY-STEP. logic
Logica CH= 5- Control con gured as STOP.
The command performs a STOP
CH logic= 6 - Control con gured as AUX0. (**)
The control activates the AUX0 output
CH logic= 7 - Control con gured as AUX1. (**)
The control activates the AUX1 output
CH logic= 8 -Control con gured as AUX2. (**)
The control activates the AUX2 output
CH logic= 9 - Control con gured as AUX3. (**)
The control activates the AUX3 output
CH logic= 10 - Control con gured as EXPO1. (**)
The control activates the EXPO1 output
CH logic= 11 - Control con gured as EXPO2. (**)
The control activates the EXPO2 output
(**) Active only if the output is con gured as Monostable Radio Channel, Courtesy Light, Zone Light, Stair Light, Bistable Radio Channel or Timed Radio Channel.
48
- RIGEL 6
INSTALLATION MANUAL
Cross out
Default setting
used
0
1
2
3
4
5
6
0
7
8
1-3
9
10
11
12
0
1
2
11
3
4-5 4
5
6
7
8
9
10
11
11
6-7
12
13
14
15
0
0
ashing
1
0
0
1
Input con gured as Start E command.
Input con gured as Start I command.
Input con gured as Open command.
Input con gured as Close command.
Input con gured as Ped command.
Input con gured as Timer command.
Input con gured as Timer Pedestrian command.
Input con gured as Phot (photocell) safety.
Input con gured as Phot op safety (photocell active during opening only).
Input con gured as Phot cl safety (photocell active during closing only).
Input con gured as Bar safety (safety edge).
Input con gured as safety Bar OP, safety edge with inversion active only while opening, if while closing
the movement stops.
Input con gured as safety Bar CL, safety edge with inversion active only while closing, if while opening
the movement stops.
Output con gured as monostable Radio Channel.
Output con gured as SCA (gate open light).
Output con gured as Courtesy Light command.
Output con gured as Zone Light command.
Output con gured as Stair Light.
Output con gured as Alarm.
Output con gured as Flashing light.
Output con gured as Latch.
Output con gured as Magnetic lock.
Output con gured as Maintenance.
Output con gured as Flashing Light and Maintenance.
Output con gured as Tra c Light control with TLB board.
Not used
Output con gured as Gate Status
Output con gured as Bistable Radio Channel
Output con gured as timed Radio Channel
Pre- ashing switched o .
Red lights ash, for 3 seconds, at start of operation.
Red lights o when gate closed.
Red lights on when gate closed.
Radio channel control con guration
Optional extras
