BFT RIGEL 6 Instructions D'installation page 41

Terminal De nition
60
61
62
63
64
65
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
Y ANTENNA
#
Aux logic= 0 - MONOSTABLE RADIO CHANNEL output.
Contact stays closed for 1s when radio channel is activated.
Aux logic= 1 - SCA GATE OPEN LIGHToutput.
Contact stays closed during opening and with leaf open, intermittent during closing, open with leaf closed.
Aux logic= 2 - COURTESY LIGHT command output.
Contact stays on for 90 seconds after the last operation.
Aux logic= 3 - ZONE LIGHT command output.
Contact stays closed for the full duration of operation.
Aux logic= 4 - STAIR LIGHT output.
Contact stays closed for 1 second at start of operation.
Aux logic= 5 - GATE OPEN ALARM output.
Contact stays closed if the leaf stays open for double the set TCA time.
Aux logic= 6 - FLASHING LIGHT output.
Contact stays closed while leaves are operating.
Aux logic= 7 - SOLENOID LATCH output.
Contact stays closed for 2 seconds each time gate is opened or closed.
Aux logic= 8 - MAGNETIC LOCK output.
Contact stays closed when gate is closed and while it is closing.
Aux logic= 9 - MAINTENANCE output.
Contact stays closed once the value set for the Maintenance parameter is reached, to report that maintenance is required.
Aux logic= 10 - FLASHING LIGHT AND MAINTENANCE output.
Contact stays closed while leaves are operating. If the value set for the Maintenance parameter is reached, once the gate has nished moving and the leaf is closed, the contact closes
for 10 sec. and opens for 5 sec. 4 times to report that maintenance is required.
INSTALLATION MANUAL
IC 1 and IC 2 inputs common
Common
Con gurable command input 1 (N.O.) - Default START E.
IC 1 START E / START I / OPEN / CLOSE / PED / TIMER / TIMER PED
Refer to the "Command input con guration" table.
Con gurable command input 2 (N.O.) - Default PED.
IC 2
START E / START I / OPEN / CLOSE / PED / TIMER / TIMER PED
Refer to the "Command input con guration" table.
IC 3 and IC 4 inputs common
Common
Con gurable command input 3 (N.O.) - Default OPEN.
IC 3 START E / START I / OPEN / CLOSE / PED / TIMER / TIMER PED
Refer to the "Command input con guration" table.
Con gurable command input 4 (N.O.) - Default CLOSE.
IC 4
START E / START I / OPEN / CLOSE / PED / TIMER / TIMER PED
Refer to the "Command input con guration" table.
Common STOP, SAFE 1 and SAFE 2 inputs common
The command stops movement. (N.C.)
STOP
If not used, leave jumper inserted.
Con gurable safety input 1 (N.C.) - Default PHOT.
PHOT / PHOT TEST / PHOT OP / PHOT OP TEST / PHOT CL / PHOT CL TEST / BAR / BAR TEST / BAR 8K2/ BAR OP / BAR OP TEST / BAR
SAFE 1
8K2 OP/ BAR CL / BAR CL TEST / BAR 8K2 CL.
Refer to the "Safety input con guration" table.
FAULT 1 Test input for safety devices connected to SAFE 1.
Con gurable safety input 2 (N.C.) - Default BAR.
PHOT / PHOT TEST / PHOT OP / PHOT OP TEST / PHOT CL / PHOT CL TEST / BAR / BAR TEST / BAR 8K2/ BAR OP / BAR OP TEST / BAR
SAFE 2
8K2 OP/ BAR CL / BAR CL TEST / BAR 8K2 CL
Refer to the "Safety input con guration" table.
FAULT 2 Test input for safety devices connected to SAFE 2.
Common SAFE 3 and SAFE 4 inputs common
Con gurable safety input 3 (N.C.) - Default PHOT OP.
PHOT / PHOT TEST / PHOT OP / PHOT OP TEST / PHOT CL / PHOT CL TEST / BAR / BAR TEST / BAR OP / BAR OP TEST / BAR CL / BAR CL
SAFE 3
TEST /
Refer to the "Safety input con guration" table.
FAULT 3 Test input for safety devices connected to SAFE 3.
Con gurable safety input 4 (N.C.) - Default PHOT CL.
PHOT / PHOT TEST / PHOT OP / PHOT OP TEST / PHOT CL / PHOT CL TEST / BAR / BAR TEST / BAR OP / BAR OP TEST / BAR CL / BAR CL
SAFE 4
TEST /
Refer to the "Safety input con guration" table.
FAULT 4 Test input for safety devices connected to SAFE 4.
Common SAFE 5 and SAFE 6 inputs common
Con gurable safety input 5 (N.C.) - Default PHOT.
PHOT / PHOT TEST / PHOT OP / PHOT OP TEST / PHOT CL / PHOT CL TEST / BAR / BAR TEST / BAR OP / BAR OP TEST / BAR CL / BAR CL
SAFE 5
TEST /
Refer to the "Safety input con guration" table.
FAULT 5 Test input for safety devices connected to SAFE 5.
Con gurable safety input 6 (N.C.) - Default BAR.
PHOT / PHOT TEST / PHOT OP / PHOT OP TEST / PHOT CL / PHOT CL TEST / BAR / BAR TEST / BAR OP / BAR OP TEST / BAR CL / BAR CL
SAFE 6
TEST /
Refer to the "Safety input con guration" table.
FAULT 6
Test input for safety devices connected to SAFE 6.
Antenna input.
Use an antenna tuned to 433MHz. Use RG58 coax cable to connect the Antenna and Receiver. Metal bodies close to the
antenna can interfere with radio reception. If the transmitter's range is limited, move the antenna to a more suitable position.
SHIELD
NTC Input for temperature sensor connection
Description
AUX output con guration
- 41
RIGEL 6
