ASSEMBLY
7. Align the holes of the boom assembly mounting
bracket with those of the actuator and insert the bolt.
Secure with nut.
A
NOTE: Be sure that the bolt is completely through the
S
holes of the boom assembly mounting bracket and
S
the actuator assembly. The boom assembly will pivot
E
easily if the mounting hardware is aligned properly when
the boom assembly is secured to the mast.
M
B
L
Y
FIGURE 5 - ASSEMBLING THE ELECTRIC ACTUATOR TO THE BOOM
Shifter Handle Installation (FIGURE 6)
1. Remove the shifter handle from the packaging car-
ton.
2. Line-up the shifter handle threads with threaded
opening in the base. Turn the shifter handle clock-
wise and securely tighten into the base
(FIGURE 6).
ASSEMBLY (CONT.)
DO NOT overtighten the nut and bolt
and bend the mounting bracket.
8. Plug-in the electrical connectors from the electric
9. Plug the pendant control into the bottom of the bat-
NOTE: The bottom of the actuator assembly
will already be assembled to the mast mounting
bracket.
FIGURE 6 - SHIFTER HANDLE INSTALLATION
8
CAUTION
actuator to the bottom of the battery assembly.
tery assembly.
Mounting Bracket
Plastic Bushing
NOTE: Turn 90
Shifter Handle
Opening in Base
o
.
Threads
