Operating Instructions
NOTE: The swivel bar and sling can also be weighed
separately, then subtracted from the total weight which
includes the patient and attaching hardware.
NOTE: The weight module will automatically turn OFF
after approximately two (2) minutes to conserve power.
If the display turns OFF before you are able to record
the patients weight, simply press the OPERATE but-
ton once again.
ACCESSORIES
HOLD FUNCTION.
With the HOLD switch in the HOLD ON position, the
display reading will FREEZE after approximately one
(1) minute (lbs./kg will flash) then automatically turn off
at the end of the two (2) minute timing cycle.
Battery Replacement
The weight module is powered by a nine (9) volt bat-
tery. This should provide approximately 3000 readings
before needing replacement.
When battery replacement is needed, a B will
appear on the display.
Simply remove the two (2) screws on the sides of the
module and slide the housing upward to access the
battery.
Calibration and maintenance should be
performed by trained factory personnel
ONLY. The load cell transducer contains no
user serviceable components. In the event
of unauthorized tampering, warranties shall
become null and void.
27
ACCESSORIES
CAUTION
A
C
C
E
S
S
O
R
I
E
S
