Assembling the Manual / Hydraulic Pump
to the Boom (FIGURE 4)
1. Remove the shoulder bolt, washer and nut from
the mounting bracket on the boom assembly.
2. Unpack the plastic bushing from the patient lift car-
ton.
NOTE: The bottom of the hydraulic pump assembly
will already be assembled to the mast mounting bracket.
3. Cut the plastic-wrap that secures the boom and
mast together.
4. Lift-up on the boom and place it on your left shoulder.
5. Let the hydraulic pump rest on the right-side of your
chest and rotate the shaft extension of the hydrau-
lic pump assembly until it lines-up with the mount-
ing bracket holes in the boom assembly.
FIGURE 4 - ASSEMBLING THE MANUAL / HYDRAULIC PUMP TO THE BOOM
Assembling the Electric Actuator to the
Boom (FIGURE 5)
1. Remove the shoulder bolt, washer and nut from
the mounting bracket on the boom assembly.
2. Unpack the plastic bushing from the patient lift car-
ton.
NOTE: The bottom of the electric actuator assembly
will already be assembled to the mast mounting bracket.
ASSEMBLY (CONT.)
6. Turn the pinch guard 90
7. Align the holes of the boom assembly mounting
NOTE: Be sure that the bolt is completely through the
holes of the boom assembly mounting bracket and the
manual / hydraulic pump assembly. The boom assem-
bly will pivot easily if the mounting hardware is aligned
properly when the boom assembly is secured to the mast.
DO NOT overtighten the nut and bolt
and bend the mounting bracket.
3. Cut the plastic-wrap that secures the boom and
4. Lift-up on the boom and place it on your left shoul-
5. Let the actuator rest on your right-side of your chest
6. Place the pinch guard over the shaft extension of
7
extension of the hydraulic pump.
bracket with those of the hydraulic pump and in-
sert the bolt. Secure with washer and nut.
CAUTION
Mounting
Bracket
Pinch Guard
o
NOTE: Turn 90 .
mast together.
der.
and rotate the shaft extension of the actuator as-
sembly until it lines-up with the mounting holes in
the boom assembly.
the actuator.
ASSEMBLY
o
and place over the shaft
A
S
S
E
M
B
L
Y
