Do all roller axes protrude the same distance
from the holders if the door is open? If
necessary, check the diagonal alignment of the
door frame.
•
Has the upper track roller been correctly
adjusted?
•
For door drives: Have the locking and the manual
cable been disassembled?
•
For NovoPort drive: Has the guide plate been
disassembled on the opposite side of the drive?
5
Operation
5.1
Safety instructions for operation
The mechanical equipment of this door is designed to
mitigate to the greatest possible extent the risk of
anyone operating or standing near the door being
crushed, cut, clipped or otherwise injured.
Observe the following safety information for safe op-
eration:
•
Use only by trained persons.
•
All operators must be instructed on how to
handle the garage door and be familiar with the
applicable safety regulations.
•
Comply with the accident prevention regulations
and general safety regulations relevant to the
field of application.
•
Regularly check the garage door for visual
defects.
•
Have the deficiencies remedied immediately.
•
Manual operation of the sectional door is only
permissible using the outer handle, inner handle,
or the manual cable. The operator must always
keep his hands away from moving parts.
•
Operation of this door is only permissible at
temperatures between -20 °C and +40 °C.
Impact and crush hazard due to the
WARNING
door movement!
When the door is actuated, the opening
and closing processes must be mon-
itored.
•
The garage door must be visible
from the place of operation.
•
Make sure that no objects or per-
sons, particularly children, are in the
door's movement area during oper-
ation.
•
Always keep the opening range
clear.
24 - EN
5.2
Opening the door
When opening the door leaf, make sure it is in its end
position. Wait until it has come to a standstill before
taking any other action.
5.3
Closing the door
When closing the door, make sure that the locking
bolt completely engages.
5.4
Lock function
Completely turning the key:
•
At all times, the sectional door can be opened
and closed without a key.
Turning the key by a 3/4 turn, then turning it back the
other way by a 3/4 turn:
•
The sectional door can be opened. After closing
the door, it will be locked again.
Opening and closing from the inside:
•
By shifting the inner unlocking/locking knob, the
door can be opened and closed without using a
key.
6
Maintenance / checks
6.1
Maintenace activities – operator
The following points must be checked and carried out
after the installation of the door and every 6 months:
•
Always grease the roller axes after approx. 5000 door
actuations. Clean horizontal rail pairs.
•
Do not apply oil on the lock cylinder. In case it
does not run smoothly enough, treat with
graphite spray.
•
Ensure sufficient ventilation (drying) of the door
frame. Water drainage must also be ensured.
•
Protect the sectional door from caustic and
aggressive agents such as acids, lyes, thawing
salts etc. Only use mild household cleaning
agents.
•
Steel-filled sectional garage doors are coated with
polyester at the factory. Any paintwork on site must
be applied within 3 months from delivery using 2C
epoxy primer containing solvents and, once
hardened, standard paint.
•
Touch up the paint at intervals as required by
local environmental and atmospheric conditions.
6.1.1 Cleaning
We recommend wiping the door regularly with a soft,
damp cloth. If necessary, use a mild cleaning agent
or soap with lukewarm water. Avoid using any polish-
ing agents or abrasive or organic solvents/cleaning
agents. Before cleaning, flush the door and glazing
thoroughly with water to avoid scratches caused by
dust particles.
These assembly, operation and maintenance instructions must be kept for the entire period of use!
