Flange with stator coupling
SW 3
for (4x) M3 screw
50 - EN
Flange with flexible torque stop
27021597825818123
Assembly requirements
During the assembly, make sure that
• The torque stop is mounted in not pre-tensioned condition
• The nuts are secured against loosening.
• The torque stop shows no deformation.
• The used slot of the fastening arm has not been damaged
• Comply with the maximum permissible shaft offset.
SW 3
on a M4 threaded rod with two M4 nuts.
when shortening.
BA Sendix® 58xxFS2 / 58xxFS3 - R60049.0009 - 04
18014398571080971
