General technical data of the SinCos interface
Max. frequency -3dB
Short-circuit resistance
Number of pulses
Offset
Offset difference between A
and B
Amplitude
Amplitude difference
between A and B
Phase position A vs. B
Terminating resistor
Safety data for the Sendix 58xxFS2 encoders
Relevant Standards
Classification
System structure
PFH value
d
Service life
44 - EN
400 kHz
Yes
1024 / 2048 ppr
2.5 V (± 100 mV)
max. 25 mV
1 V (± 10%)
pp
max. 40 mV
90° (± 10%)
120 Ω
EN ISO 13849-1:2015
EN ISO 13849-2:2012
EN 61800-5-2:2007
PLd / SIL2
2 channels (cat. 3)
-8 -1
2.16 x 10 h
20 years
Safety data for the Sendix 58xxFS3 encoders
Relevant Standards
Classification
System structure
PFH value
d
Service life
Safety assessment of the standard part of the
encoders
MTTF value
d
Diagnostic coverage
Category
EMC
Relevant Standards
BA Sendix® 58xxFS2 / 58xxFS3 - R60049.0009 - 04
EN ISO 13849-1:2015
EN ISO 13849-2:2012
EN 61800-5-2:2007
PLe / SIL3
2 channels (cat. 4)
-8 -1
1.09 x 10 h
20 years
90 years
0 %
1-channel
EN 55011 class
B:2009 / A1:2010
EN 61326-1:2013
EN 61326-3-1:2008
