AVENTICS | SERCOS III | R412012610–BDL–001–AB
6

Assembly

6.1 Assembling the valve system with the bus
coupler
You will receive your individually configured valve system
completely fitted with all components:
W
Valve terminal
W
Bus coupler
The operating instructions accompanying the VS describe in full
how to assemble the entire valve system. Any mounting
orientation may be used with the VS. The dimensions of the
complete VS vary according to module equipment (see Fig. 3).
6.1.1

Dimensions

33 9
Fig. 3: Dimensioned drawing for the valve system (bus coupler and valves)
Dimensions A and B depend on the valve block used.
A + 33
B + 33
61
Assembly
