Parameters Setting range
Min / Max
Feed temper- 0 – 4
ature, over-
shoot (*)
Feed temper- 20 – 90 °C
ature, heating
mode
Feed temper- 10 – 90 °C
ature, reducing
mode
Max. feed tem- 20 – 90 °C
perature
Min. feed tem- 10 – 90 °C
perature
Room influ-
ence
Off
0 K
1 – 20 K
Room sensor -5 – +5 K
adaptation
Heating curve
adaptation
Off
On
Interlink tem- 1 – 50 K
perature in-
crease
Daikin RoCon+ HP
Daikin controller RoCon+ HP1
008.1447899_00 – 09/2019 – EN
Description
This function defines how far the water temperature may exceed the feed
target temperature before the compressor is stopped. The compressor re-
sumes operation when the feed temperature falls below the target feed
temperature. This function ONLY applies to heating mode.
Only if [Weather-compensated] parameter = Weather-compensated:
Setting of the target feed temperature for the heating circuit during the
heating time in operating mode: "Automatic 1", "Automatic 2", "Heating".
Only if [Weather-compensated] parameter = Weather-compensated:
Setting the target feed temperature for the heating circuit during the set-
back time for the operating mode: "Automatic 1", "Automatic 2", "Heating".
The setting limits the feed temperature (measured at t
ing support function.
The determined target feed temperature of the HC is limited to the max-
imum value set here.
If an optionally connected mixed HC requests a higher temperature of the
heat generator, this is taken into account. This means the internal circula-
tion pump of the heat generator always runs if the generator is switched
on. If the direct HC supplies the floor heating, a mechanical temperature
limiter must be installed to prevent any overheating of the screed.
The determined flow target temperature of the heating circuit is limited to
the minimum value set here.
Only with the room control connected and assigned to the HC:
The setting of what influence the deviation of the room temperature meas-
ured by EHS157034 from the current target value (see
the feed temperature.
Purely weather-compensated feed temperature control
Purely weather-compensated feed temperature control, but internal circula-
tion pump continues running until the next heating cycle after a heat re-
quirement during the setback cycle.
Causes a correction of the target feed temperature (parallel shift of the
heating curve) by the set factor. If the measured temperature lies 2 K be-
low the target value, the target feed temperature is increased by 2x the set
value.
Only with room control connected and assigned to the HC.
Individual adjustment of the room temperature relevant to the controller.
If a systematic deviation of the room temperature measured by the
EHS157034 to the actual temperature in the occupied area of this room is
determined, the measured value can be corrected by the set value.
The function can only be carried out with a room controller connected and
assigned to the HC:
Deactivated
Activated = start of a one-time automatic heating curve adaptation.
Prerequisites:
▪ Outside temperature < 8 °C
▪ Setting of the operating mode: "Automatic 1" or "Automatic 2"
▪ Duration of the setback period is at least 6 hours
Function: At the start of the setback time, the current room temperature is
set as the target value for the following 4 hours. The heating curve that is
required to maintain this room temperature is determined from the target
feed temperature by the controller.
If the automatic heating curve adaptation is interrupted, the function
pauses until the adaptation is successfully carried out or ended the next
day (setting the parameter to "Off" or changing the current operating
mode).
Domestic hot water preparation and heating optimisation is locked during
the automatic heating curve adaptation.
Only if [Interlink function] parameter = On:
Feed target temperature is increased by the set value when the cooling RT
switching contact is closed. Request, e.g. by HP convector.
7 Parameter settings
Factory
setting
3
40 °C
10 °C
) with active heat- 80 °C
V2
10 °C
Chap. 4.2) has on
0.0 K
5 K
Incre- Access
ment
BE HF
1 N E
1 °C E E
1 °C E E
1 °C N E
1 °C N E
1 K E E
1 K E E
- N E
1 K N E
