flamco Meibes MeiFlow TOP S-Line MC-X Instructions De Montage page 11

2.2 PG UC-X, DN25, Kvs=6.8 m³/h
Visual representation
Legend:
Pos.
1A
1B
2
3A
4
5
6
7
8
10
d
e
f
g
Components
RL ball valve with detachable handle and thermometer
FL ball valve with detachable handle and thermometer
backflow preventer, in ball valve, openable
RL pipe as T-piece
Sensor mounting for FL temperature sensor
Plastic pipe bracket for wall-mounted installation
Heating circuit pump
Three-way mixer with bypass (for any servomotor)
EPP housing as multipart thermal insulation
Opening for cable grommet
Connections:
Cooling circuit RL
Cooling circuit FL
Cooling station RL
Cooling station FL
Note: example representation
We reserve the right to change designs and technical specifications of our products.
Design and components
Notes
blue scale, 0-120°C
red scale, 0-120°C
Cracking pressure 200 mm WC
M10x1
Hole for bolt Diam. 12 mm, T=66 mm
IL=180 mm, 1 ½" flat sealing
mountable on left-hand variant
has fire protection class B2 - normal flammability
2 x 4 mm diameter
1" MT
1" MT
Dimensions in [mm]
A1
A2
B
C
H1
H2
H3
H4
H5
125
74
249
220
421
472
359.5
315
180
11
