4 Mechanical installation
Standard devices in the power range 75 ... 90 kW

Mounting with fixing brackets (standard)

4.5 Standard devices in the power range 75 ... 90 kW
4.5.1 Mounting with fixing brackets (standard)
Mounting material required from the scope of supply:
Description
Fixing bracket
Hexagon head cap screw M8 × 16 mm
(DIN 933)
Washer Æ 8.4 mm (DIN 125)
Spring washer Æ 8 mm (DIN 127)
134
Use
Drive controller fixing
For fixing bracket
For hexagon head cap screw
For hexagon head cap screw
l
Quantity
4
8
8
8
EDK82EV903 DE/EN/FR 5.1
