8 Troubleshooting and fault elimination
Fault elimination
Fault messages
1)
Keypad PC Fault
54 Controller
OH4
a
overtemperature
203 PTC monitoring
OH51
(display when
C0119 = 2 or 5)
− DC−bus overvoltage
OU
c
(message or TRIP
configurable in C0310)
22
OUE
a
75 Faulty parameter
Pr
a
transfer via keypad
72 Faulty PAR1 transfer via
Pr1
a
keypad
73 Faulty PAR2 transfer via
Pr2
a
keypad
77 Faulty PAR3 transfer via
Pr3
a
keypad
78 Faulty PAR4 transfer via
Pr4
a
keypad
79 Internal fault
Pr5
a
81 Time error during
Pt5
a
parameter set transfer
76 Error during Auto−TRIP
rSt
a
reset
85 Wire breakage, analog
sd5
a
input 1
87 Wire breakage, analog
sd7
a
input 2
1)
LECOM error number, display in Global Drive Control (GDC) parameter setting program
188
Cause
Controller is too hot inside
Motor too hot due to impermissible
high currents or frequent and too long
acceleration processes
No PTC connected
Mains voltage is too high
Braking operation
Earth leakage at motor end
All parameter sets are defective
Parameter set 1 is defective
Parameter set 2 is defective
Parameter set 3 is defective
Parameter set 4 is defective
EEPROM is defective
Data flow from keypad or PC
interrupted, e.g. keypad has been
removed during data transmission
More than 8 error messages within
10 minutes
Current on analog input < 4 mA for
setpoint range 4 ... 20 mA
l
Remedy
l
Reduce controller load
l
Improve cooling
l
Check fan in the controller
Check drive dimensioning
Connect PTC or switch off monitoring
Check supply voltage
l
Increase deceleration times
l For operation with an external brake
resistor:
– Check dimensioning, connection and
supply cable of the brake resistor
– Increase deceleration times
Check motor supply cable and motor for
earth fault (disconnect motor from the
inverter)
Before enabling the controller, repeat the
data transfer or load the Lenze setting
Contact Lenze
Before enabling the controller, repeat the
data transfer or load the Lenze setting.
Dependent on the error message
Close the circuit at the analog input
