moving parts do not get tangled with the long grass / brush.
Move the head in steady strokes from left to right as you
work through the grass / brush.
ADVANCING THE LINE (Fig. 7)
If the line becomes short, tap the head on the ground
as shown to extend more line. Take care not to 'crash' it
against a hard surface.
OPERATING THE BRUSHCUTTER (Fig. 5)
Hold the brushcutter with the right hand on the trigger
handle and the left hand on the left handle.
Keep a firm grip with both hands while in operation.
Brushcutter should be held at a comfortable position with
the trigger handle about hip height. Maintain your grip and
balance on both feet. Position yourself so that you will not
be drawn off balance by the kick-back reaction of the cutting
blade.
Adjust the shoulder strap to position the brushcutter at
a comfortable operating position and to assure that the
shoulder strap will reduce the risk of operator contact with
the blade.
Exercise extreme caution when using the blade with this
unit. Blade thrust is the reaction which may occur when
the spinning blade contacts anything it cannot cut. This
contact may cause the blade to stop for an instant, and
suddenly "thrust" the unit away from the object that was hit.
This reaction can be violent enough to cause the
operator to lose control of the unit. Blade thrust may
occur without warning if the blade snags, stalls or binds.
This is more likely to occur in areas where it is difficult to
see the material being cut. For cutting ease and safety,
approach the weeds being cut from the right to the left.
In the event that an unexpected object or woody stock is
encountered, this could minimise the blade thrust reaction.
CUTTING TECHNIQUE - BLADE (Fig. 8)
ARNING
Extreme care must be taken when using blades to
ensure safe operation. Read the safety information
for safe operation using the blade, refer to "Specific
Safety Rules for Brushcutter and Blade Use" earlier
in this manual.
MAINTENANCE
ARNING
Neglected or poorly conducted maintenance may
create additional hazards. Do not attempt to repair
or maintain this product if you are not qualified to
do so. If in doubt, return to a Ryobi service centre
for professional assistance.
ARNING
Use only original manufacturer's replacement parts,
PT NL SV DA NO FI
English (Original Instructions)
HU CS RU RO PL SL
accessories and attachments. Failure to do so can
cause possible injury, poor perfor-mance and may
void your warranty.
You may make adjustments and repairs described
here. For other repairs, have the trimmer serviced by an
authorized service agent.
Consequences of improper maintenance may include
excess carbon deposits resulting in loss of performance
and discharge of black lubricanty residue dripping from
the silencer.
Make sure all guards, straps, deflectors and handles
are properly and securely attached to avoid the risk of
personal injury.
LINE REPLACEMENT (Fig. 9)
Ensure the unit is in the off position
Remove the spark plug lead, to prevent accidental
starting.
Use 2.4mm diameter monofilament string.
Cut one piece of string approximately 6.0m in length
Rotate knob on string head until line on knob aligns
with arrows on top of string head.
Insert one end of string into eyelet located on the
side of the string head and push until string comes
out through eyelet on the other side. Continue to
push string through the string head until the middle
section of the string is inside the string head and
string outside the string head is evenly divided on
each side.
Rotate the knob on the string head clockwise to wind
the string
Wind the string until approximately 20cm remains
protruding from the string head.
BLADE PROTECTOR (Fig. 10)
Always place the blade protector on the blade when the unit
is not in use. The blade protector has clips round the edges
to snap over the blade and keep it in place. Wear gloves
and be cautious when handling the blade.
NOTE: Always remove the blade protector before using the
unit. If not removed, the blade protector could become a
thrown object as the blade begins to turn.
CLEANING THE EXHAUST PORT AND
SILENCER
Depending on the type of fuel used, the type and amount
of lubricant used, and/or your operating conditions, the
exhaust port and silencer may become blocked with
carbon deposits. If you notice a power loss with your petrol
powered tool, a qualified service technician will need to
remove these deposits to restore performance.
CLEANING THE AIR FILTER SCREEN (Fig. 11)
19
