STARGAS _____________________________________________________________________ LAMBDA PROBE TEST
•
Select the SIMULATION function from the
•
Select the function ( 133 ) to set the kind of lambda probe used to carry
out the test (1 V or 5 V); usually it is set to 1 V.
•
Select the MEASURE function ( 132 ) to start the test.
In the SIMULATION page, in the lower box on the left, the CO values and
the lambda coefficient correspond to the ones that have been measured by
means of the gas sampling probe.
•
Select the function ( 134 ) to display in the RICH MIXTURE ( 137 ) square,
having a RED background, the CO and lambda factor values that vary
as a function of the mixture enrichment.
OPERATING INSTRUCTIONS
λ
PROBE TEST page.
137 136
132
133
134
135
