Logic Definition
TRAFFIC LIGHT
Traffic light pre-
flashing
PREFLASHING
TRAFFIC LIGHT
Steadily lit red light
RED LAMP
ALWAYS ON
*
Only active on FW > 1.12
CH logic= 0 - Control configured as Start E. Operation according to STEP-BY-STEP MOV. logic. External start for traffic light control.
CH logic= 1 - Control configured as Start I. Operation according to STEP-BY-STEP MOV. logic. Internal start for traffic light control.
CH logic= 2 - Control configured as Open.
The command causes the leaves to open.
CH logic= 3 - Control configured as Closed.
The command causes the leaves to close.
CH logic= 4 - Control configured as Ped.
The command causes the leaf to open to the pedestrian (partial) opening position. Operation according to STEP-BY-STEP. logic
Logica CH= 5- Control configured as STOP.
The command performs a STOP
CH logic= 6 - Control configured as AUX0. (**)
The control activates the AUX0 output
CH logic= 7 - Control configured as AUX1. (**)
The control activates the AUX1 output
CH logic= 8 -Control configured as AUX2. (**)
The control activates the AUX2 output
CH logic= 9 - Control configured as AUX3. (**)
The control activates the AUX3 output
CH logic= 10 - Control configured as EXPO1. (**)
The control activates the EXPO1 output
CH logic= 11 - Control configured as EXPO2. (**)
The control activates the EXPO2 output
(**) Active only if the output is configured as Monostable Radio Channel, Courtesy Light, Zone Light, Stair Light, Bistable Radio Channel or Timed Radio Channel.
TABLE "C" – RADIO MENU (RADIO)
Logic Description
Add 1ch Key
add 1ch
associates the desired key with the 1nd radio channel command.
Add 2ch Key
add 2ch
associates the desired key with the 2nd radio channel command.
Add 3ch Key
add 3ch
associates the desired key with the 3nd radio channel command.
Add 4ch Key
add 4ch
associates the desired key with the 4nd radio channel command.
Erase List
WARNING! Erases all memorized transmitters from the receiver's memory.
erase 64
Eliminates individual radio control
Removes a radio control (if clone or replay is disabled) To select the radio control to be deleted, enter the position or press a button on the radio
erase 1
control to be deleted (the position is displayed)
Read receiver code
Displays receiver code required for cloning transmitters.
INSTALLATION MANUAL
Cross out
Default setting
used
0 Pre-flashing switched off.
0
1 Red lights flash, for 3 seconds, at start of operation.
0 Red lights off when gate closed.
0
1 Red lights on when gate closed.
Radio channel control configuration
Optional extras
