Logic Definition
Configuration of
command input IC 3.
IC 3
64
Configuration of
command input IC 4.
IC 4
65
Configuration of the
1st radio channel
1ch
command
Configuration of the
2nd radio channel
2ch
command
Configuration of the
3rd radio channel
3 ch
command
Configuration of the
4th radio channel
4 ch
command
Configuration of
AUX 0
AUX 0 output. 20-21
Configuration of
AUX 1 output.
AUX 1
22-23
Configuration of
AUX 2 output.
AUX 2
24-25
Configuration of
AUX 3 output.
AUX 3
26-37
Type of lock.
LOCK
28-29
Fixed code
FIXED CODE
Protection
Setting the
protection level
level
INSTALLATION MANUAL
Cross out
Default setting
used
4 Input configured as Ped.
2
5 Input configured as Timer.
3 6 Input configured as Timer Pedestrian.
0 Radio control configured as START E.
0 1 Radio control configured as Start I.
2 Radio control configured as Open.
3 Radio control configured as Close
4 Radio control configured as Ped
9
5 Radio control configured as STOP
6 Radio control configured as AUX0 **
7 Radio control configured as AUX1 **
2 8 Radio control configured as AUX2 **
9 Radio control configured as AUX3 **
10 Radio control configured as EXPO1 **
5
11 Radio control configured as EXPO2 **
0 Output configured as monostable Radio Channel.
6 1 Output configured as SCA (gate open light).
2 Output configured as Courtesy Light command.
3 Output configured as Zone Light command.
3 4 Output configured as Stair Light
5 Output configured as Alarm
6 Output configured as Flashing light
1 7 Output configured as Latch
8 Output configured as Magnetic lock
9 Output configured as Maintenance
10 Output configured as Flashing Light and Maintenance.
11 Not used
0 12 Not used
13 Output configured as Gate Status
14 Output configured as Bistable Radio Channel
15 Output configured as timed Radio Channel
0 Output configured as 12V
0
1
Output configured as 12V
Receiver is configured for operation in rolling-code mode.
0
Fixed-Code Clones are not accepted.
0
Receiver is configured for operation in fixed-code mode.
1
Fixed-Code Clones are accepted.
A - The password is not required to access the programming menus
B - Enables wireless memorizing of transmitters.
Operations in this mode are carried out near the control panel and do not require access:
- Press in sequence the hidden key and normal key (T1-T2-T3-T4) of a transmitter that has already been
memorized in standard mode via the radio menu.
- Press within 10 sec. the hidden key and normal key (T1-T2-T3-T4) of a transmitter to be memorized.
The receiver exits programming mode after 10 sec.: you can use this time to enter other new transmitters
0
by repeating the previous step.
C - Enables wireless automatic addition of clones.
Enables clones generated with the universal programmer and programmed Replays to be added to the
receiver's memory.
D - Enables wireless automatic addition of replays.
Enables programmed Replays to be added to the receiver's memory.
E - The board's parameters can be edited via the U-link network
A - You are prompted to enter the password to access the programming menus
1 The default password is 1234.
No change in behaviour of functions B - C - D - E from 0 logic setting
0 A - You are prompted to enter the password to access the programming menus
The default password is 1234.
2
B - Wireless memorizing of transmitters is disabled.
C - Wireless automatic addition of clones is disabled. No change in behaviour of functions D - E from 0 logic setting
A - You are prompted to enter the password to access the programming menus
The default password is 1234.
3 B - Wireless memorizing of transmitters is disabled.
D - Wireless automatic addition of Replays is disabled.
No change in behaviour of functions C - E from 0 logic setting
A - You are prompted to enter the password to access the programming menus
The default password is 1234.
B - Wireless memorizing of transmitters is disabled.
C - Wireless automatic addition of clones is disabled.
4 D - Wireless automatic addition of Replays is disabled.
E - The option of editing the board's parameters via the U-link network is disabled.
Transmitters are memorized only using the relevant Radio menu.
IMPORTANT: This high level of security stops unwanted clones from gaining access and also stops radio
interference, if any.
