BFT RIGEL 6 Instructions D'installation page 45

Parameter min. max.
0 99
obst. s ens.
0 250
Maintenance
(*) In the European Union, apply standard EN 12453 for force limitations, and standard EN 12445 for measuring method.
(**) The impact forces must be limited using active coasts comply with EN12978
(***) CAUTION: After a parameter change will need to run an autoset function if the "obstacle sensitivity" is active.
TABLE "B" - LOGIC MENU - (logic)
Logic Definition
Automatic Closing
TCA
Time
Fast closing
FAST CLS.
STEP-BY-STEP
Step-by-step
movement
MOVEMNT
Pre-alarm
PRE-ALARM
INSTALLATION MANUAL
Default Personal Definition
0 Obstacle sensitivity
Programming number of
operations for maintenance
0
threshold
[in hundreds]
Cross out
Default setting
used
0 Logic not enabled
0
1 Switches automatic closing on
0 Logic not enabled
0
1 Closes 3 seconds after the photocells are cleared before waiting for the set TCA to elapse.
Inputs configured as Start E, Start I,
0
Ped operate with 4-step logic.
Inputs configured as Start E, Start I,
1 Ped operate with 3-step logic. Pulse
during closing reverses movement.
0
Inputs configured as Start E, Start I,
2 Ped operate with 2-step logic. Move-
ment reverses with each pulse.
0 The flashing light comes on at the same time as the motor(s) start.
0
1 The flashing light comes on approx. 3 seconds before the motor(s) start.
Description
It allows activating obstacle detection.
The function is disabled when the parameter is set to 0, setting the value between 1 and
the maximum value, obstacle sensitivity can be increased (max value = max sensitivity).
ATTENTION: This obstacle detection function does not guarantee com-
pliance with the safety regulations in force (*). To comply with the current safety
regulations, install adequate anti-crushing safety devices (**).
ATTENTION: The system detects the obstacle only if the leaf is stopped; no
obstacles breaking the leaf without managing to stop it are detected.
Detection takes place only if the leaf meeting the obstacle is moving at normal
speed. The obstacle is not detected during slow-down.
The movement of the leaf is divided into these phases:
1 2
ACTIVE
1= Pick-up
2= Operating speed
3= Slowdown
4= Overtravel
The function is only active in phase 2.
If the slowdown is not present (phase 3 not present), the last part of phase 2 (last 10% of
the operating phase, with a maximum limit of 9 seconds) is also deactivated
1 2
ACTIVE
(up to a maximum of 9 seconds)
1= Pick-up
2= Operating speed
4= Overtravel
Do not use this function with hydraulic motors.
Leave default value set to 0.
(***)
Allows you to set a number of operations after which the need for maintenance will
be reported on the AUX output configured as Maintenance or Flashing Light and
Maintenance .
Optional extras
2 STEP
CLOSED
OPENS
DURING
CLOSING
OPEN
CLOSES
DURING
OPENING
AFTER STOP OPENS
3 4
4
10%
NOT ACTIVE
-10% of the course
step-by-step mov.
3 STEP 4 STEP
OPENS
OPENS
STOPS
CLOSES CLOSES
STOP + TCA STOP + TCA
OPENS OPENS
RIGEL 6
- 45
