7. MANAGER

7.3 TANKS

7.3.1 TANKS
You can change the stock level and then you have to press the SET button.
NOTE: The maximum quantity has to be lower than the capacity
of the tank.
The upper part of the pop up window shows the percentage of the filling
percentage and a semicircle that shows the filling sector.
Ninth column: It shows if there is a connected probe or not. If so, an icon
will appear:
: Volumetric Probe
: Contact Probe

7.3.2 MOBILE UNITS

• First column: There is a little picture of the device (mobile unit in
this case).
• Second column: The mobile unit address is shown.
• Third column: If shows if the tank is for delivery (fresh product)
or recovery (used product)

7.3.3 TANK TRUCKS

• First column: There is a little picture of the device (mobile unit in
this case).
• Second column: The tank truck address is shown.
• Third column: If shows if the tank is for delivery (fresh product)
or recovery (used product)
• Fourth column: It shows a combination of the name of the tank
and the name & reference of the fluid that is contained in the tank.
• Fifth column: It shows the contained quantity, the maximum
capacity and the percentage. For instance, for tank 1 the contained
quantity 200 litres, the maximum quantity is 2000 litres and the
percentage is 10 %.
• Sixth column: It shows the warning and the stop levels set in the
configuration menu.
In the upper right part of the window there are three icons.
40
838 861 R. 11/21
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: +34 985 381 488 · www.samoaindustrial.com
.
.
• Fourth column: It shows a combination of the name of the tank
and the name & reference of the fluid that is contained in the tank.
• Fifth column: It shows the contained quantity, the maximum
capacity and the percentage. For instance, for tank 1 the contained
quantity 200 litres, the maximum quantity is 2000 litres and the
percentage is 10 %.
• Sixth column: It shows the warning and the stop levels set in the
configuration menu.
The first one refreshes the readings; the second one allows to make a
search in the table and the third one allows to export data to a
MS Excel spreadsheet.
