6. SOFTWARE CONFIGURATION
6.2.2 DEVICES
6.2.2.11 MOBILE UNIT
In that window you have to fulfil the following data:
• Model: Insert a name for that model of tank
• Supplier: Insert the supplier of the tank (this is a compulsory data)
• Select Dimension Type: If this option is chosen, another window
appears. This window shows the three possible predefined models:
parallelepiped, horizontal cylinder and vertical cylinder. In each
option, the main parameters are requested.
• Capacity: Once you have inserted the dimension type, the capacity
will appear automatically.
• Gauging Scales: Once you have inserted the dimension type, the
gauging scale will appear automatically.
• Select Management Type: You can choose either the tank is used
for fresh product or waste product.
Once you have set all the parameters, please press

6.2.2.12 LUBE TRUCK

First of all I have to say that this is considered as a tank although it is a
set of UValve / UDat. In this menu you have to define the parameters of
the tank that contains each product already defined in the previous tab.
• Description: You can make a brief description of the Mobile Unit.
• Local Address: The system sets a local address automatically. You
can rename it just in case you need it.
• Select Product: You have to choose the product that is contained
in the tank. The products will be the ones already defined in the
previous tab.
In that window you have to fulfil the following data:
• Model: Insert a name for that model of tank
• Supplier: Insert the supplier of the tank (this is a compulsory data)
• Select Dimension Type: If this option is chosen, another window
appears. This window shows the three possible predefined models:
parallelepiped, horizontal cylinder and vertical cylinder. In each
option, the main parameters are requested.
• Capacity: Once you have inserted the dimension type, the capacity
will appear automatically.
• Gauging Scales: Once you have inserted the dimension type, the
gauging scale will appear automatically.
• Select Management Type: You can choose either the tank is used
for fresh product or waste product.
• Stock: You can set the stock contained in the tank of the truck.
Once you have set all the parameters, please press
In the upper part of the Devices Screen you will see five icons:
• Zoom in: This option makes the icons bigger.
• Zoom out: This option makes the icons smaller.
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: +34 985 381 488 · www.samoaindustrial.com
and then .
• Choose a colour: You can associate a colour to the product
contained in the tank.
• Select Tank: You can choose the shape of the tank. If you click, you
will see a drop-down menu. In that menu you will find several
predefined tanks.
• In any case, if the installed tank is not in the list, you can define the
tanks with the
appear.
and then .
button. If you press it a popup window will
